Samsung ES25 User Manual

082
Before contacting a service center
The flash does not fire
å
Flash off mode has been selected
Ã
Disengage flash off mode
å
The camera mode can't use the flash
Ã
Refer to the FLASH instruction (p.31)
Incorrect date and time is displayed
å
The date and time have been set incorrectly or the camera has
adopted the default settings
Ã
Reset the date and time correctly
The camera buttons do not operate
å
Camera malfunction
Ã
Remove / reinsert battery and switch the camera on
A card error has occurred while the memory card is in the camera
å
Incorrect memory card format
Ã
Reformat the memory card
The images don't play back
å
Incorrect file name (Violation of DCF format)
Ã
Do not change the image file name
Color of image is different to the original scene
å
White balance or effect setting is incorrect
Ã
Select appropriate White balance and effect
Images are too bright
å
Exposure is excessive
Ã
Reset exposure compensation
No image on external monitor
å
The external monitor has not been connected properly with
the camera
Ã
Check the connection cables
å
There are incorrect files on the memory card
Ã
Insert a memory card that has correct files
When using the PC’s explorer, the [Removable Disk] le does not show
å
Cable connection is incorrect
Ã
Check the connection
å
The camera is off
Ã
Turn the camera on
å
The operating system is not Windows XP, Vista, 7 / Mac OS 10.3.
Alternatively the PC does not support USB
Ã
Install Windows XP, Vista, 7 / Mac OS 10.3 to PC that
supports USB
A part of the LCD screen does not occasionally turn on or a spot appears
å
Although the LCD screen is manufactured with high precision
technology, the precision pixels are not occasionally lighted or the
red, white and blue spots appear
Ã
This phenomenon does not affect the quality of the recorded
image and it is not a malfunction
A vertical line appears on the LCD screen when taking a picture of
a bright object
å
If a subject is exposing bright lights, a gray, black, red or purple
vertical line may appear
Ã
This is a phenomenon called smear and it does not affect the
quality of the recorded image. This is not a malfunction

Samsung ES25 Specifications

General

Megapixel	12.2 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Digital zoom	3 x
Optical zoom	4 x
Focal length range	4.9 - 19.6 mm
Interface	USB 2.0, AV out (PAL/ NTSC)
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	Intel Pentium III / 500 MHz+, Power Mac G3+
Dimensions (WxDxH)	96.3 x 23.5 x 61 mm
Camera shutter speed	1/8 - 1/2000 s
Minimum storage drive space	250 MB
Minimum system requirements	CD - ROM DirectX 9.0+
Compatible operating systems	Win 2000 / XP / Vista Mac OS 10.3+
Focal length (35mm film equivalent)	27 - 108 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞ m
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Macro focusing range (tele)	0.7 - 1 m
Macro focusing range (wide)	0.05 - 0.8 m
Auto Mode focusing range (tele)	0.7 - ∞ m
Auto Mode focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, Auto
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 1.59 m
Flash range (wide)	0.2 - 2.68 m
Flash recharging time	4 s
Internal memory	9.8 MB
Compatible memory cards	sd, sdhc
Maximum memory card size	8 GB
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Silver
Scene modes	Backlight, beach, Children, Close-up (macro), dusk, Fireworks, Night, Night landscape, Night portrait, Portrait, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Tungsten
Camera playback	movie, single image, slide show, thumbnails
Power requirements	4.2V
Bundled software	Intelli-Studio CD, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	23.5 mm
Width	96.3 mm
Height	61 mm
Weight	114 g
