Samsung LN40B540 - Page 53

5-50
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 CN7_5 3701-001367 CONNECTOR-HDMI;19P,2R,FEMALE,SMD,AU 1 S.A
....4 CN901 3701-001367 CONNECTOR-HDMI;19P,2R,FEMALE,SMD,AU 1 S.A
....4 CN902 3701-001367 CONNECTOR-HDMI;19P,2R,FEMALE,SMD,AU 1 S.A
....4 CN330 3711-005925 HEADER-BOARD TO CABLE;BOX,51P,1R,0.5mm,S 1 S.N.A
....4 T0077 BN41-01157A PCB MAIN;FR-4,4,1.2T,192*158 1 S.N.A
....4 M0018 BN97-03312A ASSY MICOM;MX25L6405DMI-12G,N64A,2008.12 1 S.N.A
.....5 IC115 1107-001777 IC-FLASH MEMORY;MX25L6405DMI-12G,64Mbit, 1 S.A
....4 HD804 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
...3 T0066 BP62-00017A HEAT SINK-ES;SP-50L2HX,A6063S,T2.0,26.2, 1 S.N.A
0.1 M0019 BN92-04270A ASSY LABEL;LN32B550K1FXZA 1 S.N.A
0.1 M0003 BN92-04286A ASSY BOX;LB550 37 (UO) 1 S.N.A
..2 M0521 BN69-03489A BOX-SET,IN;37LB450,CB,C-01,DW1,YEL,W1470 1 S.N.A
..2 BN69-03552A BOX-SET,OUT;37LB550,CB,C-03,DW2,YEL,W117 1 S.N.A
0.1 M0113 BN92-04299A ASSY P/MATERIAL;LB550 37 (UO) 1 S.N.A
..2 T0524 6902-001043 BAG PE;HDPE/NITRON,T0.015/T0.5,W1200,L80 1 S.N.A
..2 T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB 4 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.39 S.N.A
0.1 M0045 BN92-04308B ASSY ACCESSORY;LN37B550K1FXZA,40 1 S.N.A
..2 M0045 BN96-09589A ASSY ACCESSORY;LN37B550K1FXZA 1 S.A
...3 T0268 3903-000144 CBF-POWER CORD;DT,US,BP3/Y,U(IEC C13-RA) 1 S.A
...3 T0685 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,AAA[ LR03], 2 S.N.A
...3 T0524 6902-000018 BAG PE;LDPE,T0.1,W280,L400,CLEAR,8,2,-,2 1 S.N.A
...3 AA68-03242L MANUAL FLYER-04,SAFETY GUIDE;comm,Samsun 1 S.N.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0531 BN63-05468A COVER-BOTTOM;40,LB550,HIPS,V0,BK500 1 S.A
...3 BN68-01600A MANUAL FLYER-01, LEAFLET;COMM,SAMSUNG,En 1 S.N.A
...3 T0511 BN68-01883C MANUAL USERS;B550,SAMSUNG,Eng/Spa/CF,N.A 1 S.N.A
...3 BN68-01884C MANUAL FLYER-QSG;COMM,SAMSUNG,Eng/Spa/CF 1 S.N.A
...3 M0560 BN96-01800A ASSY ACCESSORY-SCREW ZIPPER;ROME32,-,-,- 1 S.N.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
....4 ACCESSORY 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,-,-,4- 1 S.N.A
...3 T0238 BP68-00263C MANUAL FLYER-WARRANTY CARD;comm,Samsung, 1 S.N.A
...3 T0074 BN59-00852A REMOCON;LCD650,TM960,AMERICA,49 1 S.A
..2 M0045 BN96-09587B ASSY ACCESSORY-CABLE;LN32B550K1FX* 1 S.A
...3 T0268 3903-000144 CBF-POWER CORD;DT,US,BP3/Y,U(IEC C13-RA) 1 S.A
...3 T0685 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,AAA[ LR03], 2 S.N.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,-,9 1 S.N.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0074 BN59-00852A REMOCON;LCD650,TM960,AMERICA,49 1 S.A
