Samsung NP350E7C User Manual

142
Chapter 6
Appendix
The system specications may dier depending on the derived
models.
For detailed system specications, refer to the product catalogue.
CPU
(Optional)
Intel Celeron/Pentium Processor
Intel Core i3/i5/i7 Processor
AMD E1/E2/A4/A6/A8/A10 Processor
Main
Memory
Memory type: DDR3 SODIMM
Main Chipset
(Optional)
Intel HM70/HM76
AMD A68M/A70M
Storage
Device
9.5mmH SATA2
Graphics
Intel® HD Graphics
Intel® HD Graphics 3000 (Internal)
Intel® HD Graphics 4000 (Internal)
AMD Radeon™ HD 7420G Graphics (Internal)
AMD Radeon™ HD 7520G Graphics (Internal)
AMD Radeon™ HD 7640G Graphics (Internal)
AMD Radeon™ HD 7660G Graphics (Internal)
AMD Radeon™ HD 7470M Graphics
AMD Radeon™ HD 7670M Graphics
AMD Radeon™ HD 7730M Graphics
AMD Radeon™ HD 7520G + 7670M Dual Graphics
AMD Radeon™ HD 7640G + 7670M Dual Graphics
AMD Radeon™ HD 7660G + 7670M Dual Graphics
Operating
Environment
Temperature: -5~40°C for storage,
10~32°C when operating
Humidity: 5~90% for storage,
20~80% when operating
AC/DC Rating
(Optional)
Input: 100-240VAC, 50/60Hz,
Output: 19VDC 3.16A, 19VDC 4.74A
PC Rating
(Optional)
19VDC 3.16A (60W) / 19VDC 4.74A (90W)
Optional components may not be provided or dierent •
components may be provided depending on the computer
model.
The system specications are subject to change without •
notice.
The Storage device capacity of a computer in which •
Recovery is installed, is represented as smaller than the
product specication.
The amount of memory that Windows can use may be •
smaller than the actual amount of memory available.
Product Specications

Samsung NP350E7C Specifications

General

Bus type	DMI
Stepping	E1
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-3630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	PGA988
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	24
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM76 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory slots (available)	0
Memory layout (slots x size)	2 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	17.3 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	AMD Radeon HD 7670M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Number of discrete graphics cards	1
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
LightScribe	-
Audio system	SoundAlive
Speaker power	1.5 W
Number of built-in speakers	2
Front camera resolution (numeric)	1.3 MP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout	QWERTY
Bundled software	S Player, S Gallery, S Camera, PowerDVD, Settings \\r Support Centre, SW Update, Recovery, Norton Internet Security (60 days Trial), Norton Online Backup (30 days Trial) \\r ※ Software can be changed without notice
Operating system installed	Windows 8
Form factor	Clamshell
Product type	Laptop
Product color	Black
Battery capacity	48 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
Processor code	SR0UX
Processor ARK ID	71459
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	270.2 mm
Width	411.3 mm
Height	35.2 mm
Weight	2800 g
