S&C Instruction Sheet 695-510 5
Safety Information
Location of Safety Labels and Tags
Reorder Information for Safety Labels
Location Safety Alert Message Description Number
A
DANGER
Keep Away–Hazardous Voltage (“Mr. Ouch”) G-6699
B
DANGER
Hazardous Voltage–Always Consider Circuits and Components
Live...
G-6700
C
WARNING
Do Not Block Pressure-Relief Device (not visible) G-6742
D
WARNING
Before Using Voltage Tester–Always Test for Proper Operation G-9451
Figure 1. Location of Safety Labels — Model 101 (single-way) vault-mounted style unit shown.
A
B
D
C
NOTE: The Installation and
Operation Information Kit is taped to
the switchgear assembly. Designate
a location where you can easily
retrieve it and refer to it.
NOTE: The manual operating handle is
stored on a mounting stand (not visible).
