95 °F D.B. / 71 °F W
.B.
67 °F D.B. / 57 °F W
.B.
80 °F D.B. / 67 °F W
.B.
_
D.B. /
_
W
.B.
1. OPERA
TING RANGE
Maximum
Minimum
Maximum
Minimum
1
15 °F D.B.
14 °F D.B.
75 °F D.B. / 65 °F W
.B.
0 °F D.B.
T
emperature
Indoor
Air Intake T
emp.
Outdoor
Air Intake T
emp.
Cooling
Heating
7
8
10
Table of Contents
Default Chapter
3
Default Chapter
3
Sm700855
3
Safety Precautions
4
Table of Contents
6
Applicable Indoor Units
8
1 Operating Range
9
2 Specifications
10
Unit Specifications
10
SPECIFICATIONS 2-1. Unit Specifications
10
Major Component Specifications
16
Other Component Specifications
19
3 Dimensional Data
20
4 Refrigerant Flow Diagram
23
Insulation of Refrigerant Tubing
24
5 Performance Data
26
Temperature Charts
26
Cooling Capacity
49
Heating Capacity
55
6 Electrical Data
61
Electric Wiring Diagrams
61
7 Functions
64
Explanation of Functions
64
FUNCTIONS 7-1. Explanation of Functions
64
Protective Functions
70
Current Control
71
8 Troubleshooting
73
Precautions before Performing Inspection or Repair
73
TROUBLESHOOTING 8-1. Precautions before Performing Inspection or Repair
73
Trouble Diagnosis by Error Monitop Lamps
74
Contents
74
Checking the Outdoor System
75
Trouble Diagnosis of each Part
76
Trouble Diagnosis of Fan Motor
80
9 Refrigerant R410A: Special Precautions When Servicing Unit
81
Characteristics of New Refrigerant R410A
81
Checklist before Servicing
82
Tools Specifically for R410A
83
Tubing Installation Procedures
83
In Case of Compressor Malfunction
84
In Case Refrigerant Is Leaking
86
Charging Additional Refrigerant
87
Retro-Fitting Existing Systems
87
Appendix Ainstallation Instructions
88
Contents
89
Installation Site Selection
92
Diagram of Outdoor Unit Installation
102
Air Purging
106
Wiring Instructions
109
Appendix B Unit Combination Tables
