-15-
Service Adjustments with Replacing Memory IC(IC802)
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
256 OP SURROUND 0 - 1 1 Activated / Deactivated Surround
feature. (0=No Surround, 1=with
Surround.)
257 OP MPP 0 - 1 0 Activated / Deactivated MPP
feature. (0=No MPP, 1=with MPP.)
258 OP EQUALIZER 0 - 1 1 Activated / Deactivated Equalizer
Menu. (0=No Equalizer, 1=with
Equalizer.)
260 AVL-LRF 0 - 15 9
261 AVL-LAV 0 - 15 5
262 AVL-WGT 0 - 1 1 AVL Weight
263 AVL-MOD 0 - 5 2 AVL Delay Time
264 DVB-CA 0 - 255 000
265 DVB-CL 0 - 255 000
266 DVB-CH 0 - 15 8
267 OP-CLIP 0 - 4 000 Clip Management
268 DEC-LEV 0 - 31 15 FM Stereo decoder output level adjust
269 MONO-LEV 0 - 31 15 Mono Output Level Adjust
270 NIC-LEV 0 - 31 16 Nicam Output Level Adjust
271 ADC-AM-L 0 - 31 15 External AM Level Adjust
272 ADC-AV-L 0 - 31 15 External AV Level Adjust
273 E2D FE 000 Selection of Audio Output Signal on AUDEEM pin
AV
274 FFI 0 - 1 000 Fast Filter IF-PLL
275 PA-BA-MU 0 - 63 56 Preset Audio Bass Music
276 PA-TR-MU 0 - 63 46 Preset Audio Treble Music
277 PA-B1-MU 0 - 63 63 Preset Audio Equalizer Band 1 (100Hz) Music
278 PA-B2-MU 0 - 63 47 Preset Audio Equalizer Band 2 (300Hz) Music
279 PA-B3-MU 0 - 63 32 Preset Audio Equalizer Band 3 (1000Hz) Music
280 PA-B4-MU 0 - 63 47 Preset Audio Equalizer Band 4 (3000Hz) Music
281 PA-B5-MU 0 - 63 63 Preset Audio Equalizer Band 5 (8000Hz) Music
282 PA-BA-TA 0 - 63 20 Preset Audio Bass Talk
283 PA-TR-TA 0 - 63 56 Preset Audio Treble Talk
284 PA-B1-TA 0 - 63 32 Preset Audio Equalizer Band 1 (100Hz) Talk
285 PA-B2-TA 0 - 63 42 Preset Audio Equalizer Band 2 (300Hz) Talk
286 PA-B3-TA 0 - 63 52 Preset Audio Equalizer Band 3 (1000Hz) Talk
287 PA-B4-TA 0 - 63 42 Preset Audio Equalizer Band 4 (3000Hz) Talk
288 PA-B5-TA 0 - 63 32 Preset Audio Equalizer Band 5 (8000Hz) Talk
289 PA-BA-NO 0 - 63 32 Preset Audio Bass Normal
290 PA-TR-NO 0 - 63 32 Preset Audio Treble Normal
291 PA-B1-NO 0 - 63 32 Preset Audio Equalizer Band 1 (100Hz) Normal
292 PA-B2-NO 0 - 63 32 Preset Audio Equalizer Band 2 (300Hz) Normal
293 PA-B3-NO 0 - 63 32 Preset Audio Equalizer Band 3 (1000Hz) Normal
294 PA-B4-NO 0 - 63 32 Preset Audio Equalizer Band 4 (3000Hz) Normal
295 PA-B5-NO 0 - 63 32 Preset Audio Equalizer Band 5 (8000Hz) Normal
296 DSG 0 - 1 1 Gain Audio --> Out
297 FMWS 0 - 3 1 Window Size for FM Demodulator
298 AGN 0 - 1 000 FM Sound Output Gain
299 CV2 0 - 1 0
300 OVMADAPT 0 - 1 1
301 OVMTHR 0 - 15 3
302 ASD SC1 THR 0 - 31 0 Threshold for detection of first sound
carrier (SC1)
303 CHSE 0 - 3 3
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
305 AGC Speed 0 - 3 1 IF AGC Speed
306 AGC Take Over 0 - 63 26 AGC Take Over also used as TOP
when an internal AGC tuner is used.
307 OIF 0 - 63 32 Correction for DC Offset in the IF-PLL
308 IF 0 - 7 3 PLL Demodulator Frequency
309 GD 0 - 1 0 Group Delay CVBS1
310 IFO 0 - 7 0 Set Condition IFV0 Pin4344
314 AKB On/Off 000 Black Currennt Stabilisation
315 OP TELETEXT 0 - 1 1 Activated / Deactivated Teletext
features (0=No Teletext, 1=with.)
327 PMUTE AKB 0 - 255 40
328 PMUTE DEF 0 - 255 15
329 SVO IF / CVBS 1 Selected Video Output
330 BPB 0 - 1 000 Bypass Internal Sound Bandpass Filter
331 OP DVD INPUT 0 - 1 1 (0=No DVD Input, 1=with DVD Input.)
332 OP WSS 4:3 MODE 0 - 1 1 Option Zoom Mode (Auto Position) if there is
no WSS or no scart middle voltage. (0=No
WSS, Natural Wide, 1=No WSS, Normal Wide.)
333 OP SCART INPUT 0 - 2 0 (0=No Scart Input, 1=with 1 Scart Input, 2=with 2
Scart Input.)
334 TXT-H-POS 0 - 63 6 Option Zoom Mode (Auto Position) if
there is no WSS or no Scart middle Voltage
338 OSVE AV 0 - 1 0 OSVE AV
347 NLEL 0 - 255 100 Nicam Lower Error Limit
348 NUEL 0 - 255 200 Nicam Upper Error Limit
349 L HI CUT 0 - 63 26
350 TEXT EW OFFSET 0 - 255 4
351 INH EW OFFSET 0 - 255 5
352 OPTION SVM MENU 0 - 1 1
Following table shows the initial values which have been stored in the CPU ROM, and items for the service adjustments.
Service mode adjustments table in CPU ROM
