(2) If the self-diagnostics function fails to operate
Check the indoor unit.
Is the fuse blown?
Replace the controller.
Replace the circuit
board or the fuse.
No indicators illuminate and the
indoor fan does not rotate.
Check the power voltage.
Normal
Blown
37
36
38
Table of Contents
Table of Contents
3
Default Chapter
2
Special Precautions
2
Applicable Multi-Outdoor Units
4
1 Operating Range
5
2 Specifications
6
Unit Specifications
6
Major Component Specifications
16
Other Component Specifications
21
3 Dimensional Data
22
4 Refrigerant Flow Diagram
24
5 Performance Data
25
Air Throw Distance Charts
25
6 Electrical Data
30
Electric Wiring Diagrams
30
7 Functions
32
Operation Functions
32
Night Setback
33
Protective Functions
34
8 Troubleshooting
35
Precautions before Performing Inspection or Repair
35
Method of Self-Diagnostics
35
Self-Diagnostics Lamps
36
Checking the Indoor and Outdoor Units
38
Trouble Diagnosis of Fan Motor
39
Noise Malfunction and Electromagnetic Interference
40
Appendix Ainstruction Manual
41
Table of Contents
43
Electrical Requirements
44
Installation Location
44
Safety Instructions
44
Names of Parts
45
Unit Display and Operation Button
46
Remote Control Unit (Display)
47
Remote Control Unit
48
Using the Remote Control Unit
50
Operation with the Remote Control Unit
52
Operation
52
Adjusting the Fan Speed
53
Fan Only
53
Night Setback Mode
54
QUIET Mode
55
HIGH POWER Mode
55
ION Mode
55
Special Remarks
56
Setting the Timer
57
Tips for Energy Saving
59
Using the 1-Hour off Timer
59
Adjusting the Airflow Direction
60
Care and Cleaning
61
Operation Without the Remote Control Unit
61
Operating Range
64
Troubleshooting
64
Appendix B Installation Instructions
65
For Indoor Unit Installation Instructions
66
Important
67
Please Read before Starting
67
1 General
68
Tools Required for Installation (Not Supplied)
68
Accessories Supplied with Unit
68
Optional Copper Tubing Kit
68
Type of Copper Tube and Insulation Material
68
Additional Materials Required for Installation
69
2 Installation Site Selection
69
Indoor Unit
69
Embedding the Tubing and Wiring
70
3 How to Install the Indoor Unit
71
Remove the Rear Panel from the Unit
71
Make a Hole
71
Install the Rear Panel on the Wall
72
Remove the Grille to Install the Indoor Unit
73
Shape the Indoor Side Tubing
75
Wiring Instructions
75
Wiring Instructions for Inter-Unit Connections
76
Mounting
78
Drain Hose
80
4 How to Test Run the Air Conditioner
81
5 Remote Control Unit Installation Position
82
Mounting on a Wall
82
6 Address Switch
83
Address Setting of the Remote Control Unit
83
7 Connecting a Home Automation Device
84
8 Installation Check Sheet
84
SANYO Canada Inc
85
Applewood Crescent, Concord Ontario, L4K 5C7, Canada
85
