- 91 -
Pin No. Name Function Name Function I/O
257 CINEMA FILTER FILTER_IN_SENS I
152 PWM PW_PWM4 O
39 CINEMA FILTER FILTER-_OUT_SENS I
444 SDA SDA0 IIC Bus Control data O
355 SCL SCL0 IIC Bus Control Clock O
40 CEC_D O
445 RXD RXD1 Serial Control RXD I
356 TXD TXD1 Serial Control TXD O
154 SDA SDA1 IIC Bus Control data O
41 SCL SCL1 IIC Bus Control data O
65 FAN CONTROL FAN_CTL0 Fan Control_0 O
176 FAN CONTROL FAN_CTL1 Fan Control_1 O
66 FAN CONTROL FAN_CTL2 Fan Control_2 O
177 FAN CONTROL FAN_CTL3 Fan Control_3 O
178 P_FAIL PFAIL_DCT1 Power Fail Signal Input Group1 Failture : L I
67 P_FAIL PFAIL_DCT2 Power Fail Signal Input Group2 Failture : L I
282 1.0V 1.0VGA_DETECT I
179 S1.2V S1.2V_DETECT I
281 SENSOR THERM1 Thermistor1 (ROOM) I
68 SENSOR THERM2 Thermistor2 (PANEL) I
180 0.9V 0.9V_REF_DETECT I
69 ADC CPU_ADC_IN I
380 HS PW_DHS O
285 VS PW_DVS O
381 CLK PW_DCLK O
286 DEN PW_DEN O
291 RXD PW_TXD Serial Control RXD O
386 TXD PW_RXD Serial Control TXD I
292 WIRELESS_REMOTE I
293 IRRECVR2 I
294 NMI_RST I
475 SI INT I
479 ROMWE O
84 ROMOE O
399 ANALOG RGB PC_V PC_H-Sync. Input
98 ANALOG RGB PC_H PC_V-Sync. Input
209 COMPONENT1 CR1 Cr Component Video Signal 1
210 COMPONENT1 Y1 Y Component Video Signal 1
311 COMPONENT1 CB1 Cb Component Video Signal 1
102 COMPONENT2 CR2 Cr Component Video Signal 2
103 COMPONENT2 Y2 Y Component Video Signal 2
212 COMPONENT2 CB2 Cb Component Video Signal 2
104 SCART SCART_CV Composite Video Signal Input for SCART
214 ANALOG RGB PC_R/SCART PC_R Signal Input for SCART
315 ANALOG RGB PC_SOG PC Sync. on Green Signal Inpit
106 ANALOG RGB PC_G/SCART PC_G Signal Input for SCART
215 ANALOG RGB PC_B/SCART PC_B Signal Input for SCART
108 S-VIDEO S_C S_C Signal Input
318 S-VIDEO S_Y S_Y Signal Input
109 VIDEO CVBS Composite Video Signal Input
222 PW_RST
● I/O Port Table of Main CPU (IC301, PW392) _Continue
Control Port Function
To Next Page
