Saswell SAS6000UTK-7-WIFI User Manual

11
1H/1C System（1 transformer） 1H/1C System（2 transformer）
2H/2C System (1 transformer) 2H/2C System (2 transformer)
RC
Power
【
1
】
RH
(RH+RC joined by jumper)
W
Heat Relay
Y
Compressor contactor
G
Fan relay
C
24VAC common
S1/S2
Remote sensor
RC
Power (cooling transformer) 【1,2】
RH
Power (heating transformer) 【1,2】
W
Heat relay
Y
Compressor contactor
G
Fan relay
C
24VAC common
S1/S2
Remote sensor
RC
Power 【1,2】
RH
(RH+RC joined by jumper) 【1,2】
W
Heat relay 1
Y
Cool relay 1
W2
Heat relay 2
Y2
Cool relay 2
G
Fan relay
C
24VAC common
S1/S2
Remote sensor
RC
Power 【1】
RH
(RH+RC joined by jumper)
W
Heat relay 1
Y
Cool relay 1
W2
Heat relay 2
Y2
Cool relay 2
G
Fan relay
C
24VAC common
S1/S2
Remote sensor

Saswell SAS6000UTK-7-WIFI Specifications

General

Brand	Saswell
Model	SAS6000UTK-7-WIFI
Category	Thermostat
Language	English
