Schlage BE469 Installation Instructions

3f Replace the cylinder screw.
4
Replace the cable and the spacer.
4a Remove the spacer screw from the Touchscreen.
4b Rotate the spacer so the notch is aligned with the tab, then remove the
spacer from the Touchscreen.
4c Remove the existing cable from the Touchscreen and replace it with the
longer cable.
NOTE: If you are installing the lock on a door with a 1Z\x” (38
mm) hole, stop here; do not reinstall the spacer. Do replace the
spacer screw.
4d Feed the cable through the spacer, as shown.
4e Press the cable into the groove.
4f Replace the spacer as shown and rotate back into place.
4g Replace the spacer screw.
You will know the
spacer is in the right
place when the hole
in the spacer lines up
with the hole in the
Touchscreen.
5
Install the lock.
Install the lock as detailed in the Installation Guide, using the longer screws you
selected in step 2a.
NEED HELP?
Please call customer support before returning the product to the store.
Toll-Free Calling From:
U.S.A.: (888) 805-9837
Canada: (800) 997-4734
Mexico: 018005067866
Visit our web site for videos, FAQs and more: answers.schlage.com

Schlage BE469 Specifications

General

Lock Type	Deadbolt
Keyless Entry	Yes
Connectivity	Z-Wave
Battery Type	4 AA batteries
Touchscreen	Yes
Compatibility	Z-Wave
Product Type	Electronic Deadbolt
Power Source	Battery
User Codes	Up to 30
Keypad	Yes
Bump Proof	Yes
Keyway	Schlage C Keyway
Programmable Codes	Yes
Weather Resistance	Yes
Security	ANSI Grade 1
Finish Options	Bright Brass, Satin Nickel
Finish	Satin Nickel
Backset	2-3/8" or 2-3/4"
Operation	Motorized bolt
Alarm Technology	Yes, built-in alarm
