Sega Initial D User Manual

TOOLS NEEDED:
SOCKET WRENCH
13mm SOCKET
10mm SOCKET
2mm Allen Wrench
Remove these 4 13mm bolts to
remove the stopper plate
from the assembly.
Remove these 4 10mm bolts
Slide the front plate off the assembly
and off the shaft. Then remove the
belt from the two pullys of the motor
and the shaft.
Slide the shaft out of the housing
having a care for the volume pot in
the rear. Using a 2mm Allen wrench,
remove the pully from the shaft.
[P 4/6]

Sega Initial D Specifications

General

Brand	Sega
Model	Initial D
Category	Arcade Game Machines
Language	English
