Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
43
27R-FS1
SC712 QSOCZ1040CEZZ J Socket, 10-pin(EH) AD
SC713 QSOCZ1394GEZZ J Socket, 13-pin(R) AD
SC714 QSOCZ1040CEZZ J Socket, 10-pin(EV) AD
RDA501 PRDAR0045SEFW J Heat Sink, for IC501 AF
RDA630 PRDAR0044SEFW J Heat Sink, for Q630 AF
RDA671 PRDAR0033SEFW J Heat Sink, for Q671 AF
RDA680 PRDAR0043SEFW J Heat Sink, for Q680 AC
RDA701 PRDAR0031SEFW J Heat Sink, for Q701 AE
RDA702 PRDAR0012SEFW J Heat Sink, for D701 AD
RDA720 PRDAR0005SEFW J Heat Sink, for D720 AC
å SG680 QSPGH0025CEZZ J Spark Gap AC
å SG681 QSPGH0025CEZZ J Spark Gap AC
LHLDW1063SEKZ J Holder AB
LX-BZ0086TAFD J Screw AA
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-C: DUNTKA488FMF3
POWER UNIT (Continued)
PWB-E: DUNTKA591WEF0
MTS MODULE UNIT
INTEGRATED CIRCUIT
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
TRANSISTORS
Q3001 VS2SC3928AR-1 J 2SC3928AR AB
Q3002 VS2SC3928AR-1 J 2SC3928AR AB
Q3003 VS2SC3928AR-1 J 2SC3928AR AB
Q3004 VS2SC3928AR-1 J 2SC3928AR AB
CAPACITORS
[EL.··· Electrolytic]
C3001 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3003 VCQYTA1HM123K J 0.012 50V Mylar AA
C3004 VCEA0A1HW105M J 1.0 50V EL. AB
C3005 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3006 VCEA0A1HW106M J 10 50V EL. AB
C3007 VCEA0A1HW475M J 4.7 50V EL. AB
C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3009 VCEA0A1CW227M J 220 16V EL. AC
C3010 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3011 VCEA0A1HW475M J 4.7 50V EL. AB
C3012 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
C3014 VCQYTA1HM473K J 0.047 50V Mylar AB
C3015 VCEACA1HC335K J 3.3 50V EL. AC
C3016 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3017 VCEACA1CC106K J 10 16V EL. AC
C3018 VCEA0A1HW105M J 1.0 50V EL. AB
C3029 VCKYCY1HB682K J 6800p 50V Ceramic AA
C3030 VCKYCY1HB682K J 6800p 50V Ceramic AA
C3031 VCKYCY1CB473K J 0.047 16V Ceramic AA
C3032 VCKYCY1CB473K J 0.047 16V Ceramic AA
C3034 VCE9GA1HW335M J 3.3 50V EL. (N.P) AB
C3035 VCKYCY1HB681K J 680p 50V Ceramic AA
C3037 VCE9GA1HW335M J 3.3 50V EL. (N.P) AB
C3038 VCKYCY1HB681K J 680p 50V Ceramic AA
C3039 VCEA0A1CW337M J 330 16V EL. AC
C3041 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3042 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
RESISTORS
[M-Ox.··· Metal Oxide]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ4 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R3001 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R3002 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3006 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA
R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R3013 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R3017 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R3018 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R3021 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R3022 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R3023 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R3024 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
