Sharp 32f540 User Manual

8
32F540
D14 EW CORNER BOTTOM 19-81 (13h-51h) 50 (32h) Offset toward D13. 32
D15 NOISE DET LEVEL 0-3 (00h-03h) 0 (00h) 00
D18 V CENTERING 0-63 (00-3Fh) 36 (24h)
D19 V-AGC 0-1 (00h-01h) 0 (00h) 00
D20 V POSITION-VCOMP 0-7 (00h-07h) 0 (00h) 16:9 Format 00
D21 H POSITION-VCOMP 0-31 (00h-1Fh) 15(0Fh) 16:9 Format
D22 V SIZE-VCOMP 0-127 (00h-7Fh) 52(34h) 16:9 Format
D23 H SIZE-VCOMP 0-63 (00h-3Fh) 36(24h) 16:9 Format
D24 V-LINEARITY-VCOMP 0-15 (00h-0Fh) 8(08h) 16:9 Format
D25 V-C CORRECTION-VCOMP 0-15 (00h-0Fh) 10(0Ah) 16:9 Format 0B
D26 EW PARABOLA-VCOMP 0-63 (00h-3Fh) 22(16h) 16:9 Format
D27 EW TRAPEZIUM-VCOMP 0-63 (00h-3Fh) 35(23h) 16:9 Format
D28 V EHT-VCOMP 0-7 (00h-07h) 6(06h) 16:9 Format 06
D29 H EHT-VCOMP 0-7 (00h-07h) 6(06h) 16:9 Format 06
D30 EW CORNER-VCOMP 0-31 (00h-1Fh) 12(0Ch) 16:9 Format 0C
D31 EW CORNER BOTTOM-VCOMP 19-81 (13h-51h) 50(32h) Offset toward D30 32
D32 V BLK UPPER-VCOMP 0-3 (00h-03h) 2(02h) 16:9 Format 02
D33 V BLK LOWER-VCOMP 0-3 (00h-03h) 2(02h) 16:9 Format 02
D34 V CENTERING-VCOMP 0-63 (00h-3Fh) 36(24h) 16:9 Format
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
EX1 FAO VOLUME 0-50 (00h-32h) 36 (24h) 24
EX2 CC-POSITION 0-127 (00h-7Fh) 27 (1Bh)
EX3 INT 0-255 (00h-FFh) 122 (7Ah) Interrupt period adjustment. 7A
EX4 A-ATT 0-127 (00h-7Fh) 90 (5Ah) 5A
EX5 TUNER data 0-3 (00h-03h) 0 (00h) 00
EX6 Think chip-Slice LEVEL 0-255 (00h-FFh) 54 (36h) 12
EX7 RLY DELAY TIME 0-255 (00h-FFh) 0 (00h) For the power control 00
EX8 ADG ON TIME 0-255 (00h-FFh) 10 (0Ah) For the power control 0A
B. SPECIAL SETTING
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
C. OPTION SETTING
OP1 OPTION1 0-255 (00h-FFh) 245 (F5h) F5
OP2 OPTION2 0-255 (00h-FFh) 188 (BCh) 3C
OP3 OPTION3 0-255 (00h-FFh) 15 (0Fh) 8F
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
D. SOUND ADJUSTMENT
M01 INPUT LEVEL 0-15 (00h-0Fh) 7 (07h)
M02 MTS VCO 0-63 (00h-3Fh) 38 (26h)
M03 FILTER 0-63 (00h-3Fh) 36 (24h)
M04 WIDEBAND 0-63 (00h-3Fh) 28 (1Ch)
M05 SPECTRAL 0-63 (00h-3Fh) 23 (17h)
