AY/AE-A079E
AY/AE-A099E
26
7.Take the thermistor holder from evaporator. 11.Loosen 4 screws fixing control box and take out control
ass'y.
8.Take out the thermistor from evaporator.
9.Disconnect fan motor connectors and others.
10.Loose 1 screw for a pipe cover and take it out.
Loose the earth screw.
12.Loose a screw fixing drain pan ass'y.(Right side)
13.Loose 2 screws fixing drain pan ass'y.(Left side)
14.Loose a screw fixing drain hose.
To Next Page
