Sharp AE-A099E User Manual

AY/AE-A079E
AY/AE-A099E
27
19.Loosen 2 screws fixing evaporator.15.When assembling make sure that O-ring is fitted to
the drain hose.
16.Take out the drain pan ass'y.
17.Loose a screw fixing cross flow fan to motor.
20.Take out the fan bearing ass'y.
21.Take out the cross flow fan while slightly lifting the
evaporator.
18.Slide the cross fan leftward to depart from the motor
shaft and take out fan motor.
O-ring
O-ring
Drain hose
(Section)
