ENGLISH
E-13
If the inner height of the window is
between 24" (609mm) and 36.8"
(934mm) inclusive.
(1) Open the window sash and place the
window panel on the window frame.
(2) Slide the adjustment panel to fi t the
window frame height.
(3) Secure the window panel to the window
frame with 3 screws.
If the inner height of the window is be-
tween 36.8" (934mm) and 48" (1219mm)
inclusive.
(1) Attach the extension panel to the
adjustment panel.
(2) Open the window sash and place the
window panel on the window frame.
(3) Slide the adjustment and extension
panels to fi t the window frame height.
(4) Secure the window panel to the window
frame with 4 screws.
5
Cut the foam seals (adhesive type) A and
B to the proper length and attach them
to the window panel.
Attach foam seal A to the window panel and
extension panel, and attach foam seal B to
the adjustment panel.
6
Close the window sash securely against
the Window panel.
7
Cut the foam seal to an appropriate
length and seal the opening between the
side of the inner window sash and the
outer window sash.
8
Attach the bracket with a screw.
Adjustment
panel
Foam seal
Extension panel
24"~36.8"
36.8"~48"
Foam seal A
(adhesive type)
Foam seal B
(adhesive type)
Bracket
