PARTS GUIDE

No. S67M88LC4032LE280X/WH

LED BACKLIGHT TV

MODEL:

CONTENTS

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these

parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used

for after sales service only.

The contents are subject to change without notice.

VER.1

LC-32LE280X

LC-32LE280X-WH

LC-40LE280X

LC-40LE280X-WH

PartsGuide

[1] PRINTED WIRING BOARD

ASSEMBLIES

[2] LCD PANEL

[3] MAIN UNIT : DUNTKG706FM01/

[4] POWER UNIT :

DUNTKG709FM02 ( LC-

32LE280X/WH )

[5] POWER UNIT :

DUNTKG710FM02 ( LC-

40LE280X/WH )

[6] LED IR UNIT: DUNTKG677FM01

[7] CABINET & MECHANICAL

PARTS ( LC-32LE280X/WH )

[8] CABINET & MECHANICAL

PARTS ( LC-40LE280X/WH )

[9] SUPPLIED ACCESORIES

[10] PACKING PARTS ( NOT

REPLACEMENT ITEM )

[11] EXPLODED VIEW
