30
R-120DB
R-120DK
R-120DR
R-120DW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
5-10 XCPSD40P08000 Screw : 4mm x 8mm 8 AA
MISCELLANEOUS
6- 1 FROLPA089WRK0 Turntable support 1 AP
6- 2 NTNT-A060WRE0 Turntable 1 AP
6- 3 TINSEA831WRRZ Instruction book 1 AD
6- 4 FW-VZB784WREZ Switch harness 1 AF
6- 5 FW-VZB773WREZ Main wire harness 1 AR
6- 6 QW-QZA239WRZZ High voltage wire 1 AH
6- 7 TCAUAA166WRR0 DHHS caution label 1 AC
6- 8 TCAUAA258WRRZ Monitor caution 1 AC
6- 9 TCAUAA240WRR0 Screw caution 1 AC
SCREWS AND WASHERS
7- 1 XEPSD30P08KS0 Screw : 3mm x 8mm 6 AA
7- 2 XOTSD40P08000 Screw : 4mm x 8mm 20 AA
7- 3 LX-EZA042WRE0 Special screw 4 AB
7- 4 LX-CZ0052WRE0 Special screw 2 AA
7- 5 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7- 6 LX-WZA028WRE0 Special washer 1 AB
7- 7 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 8 XHPSD40P08K00 Screw : 4mm x 8mm 6 AA
7- 9 XHPSD30P06000 Screw : 3mm x 6mm 2 AA
7-10 XHTSD40P08RV0 Screw : 4mm x 8mm 6 AA
7-11 XOTSD40P12RV0 Screw : 4mm x 12mm 4 AA
7-12 XOTWW40P08000 Screw : 4mm x 8mm 2 AB
7-13 XHTSD40P08000 Screw : 4mm x 8mm 1 AA
7-14 XETSD40P08000 Screw : 4mm x 8mm 2 AA
*
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
