R-210D
30
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
∆
∆
(JF) VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
RY1 RRLY-A111DRE0 Relay (JV12S-KT) 1 AL
RY2 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
SW1 RVR-BA018WRE0 Rotary encoder 1 AH
SW2 QSW-PA016DRE0 Tact switch 1 AB
T1 RTRNPA121DRE0 Transformer 1 AT
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ6A3///-1 Zener diode (HZ6A3) 1 AC
ZD2 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
3- 2 HPNLTA151WREZ Timer sheet 1 AG
3- 3 JKNBKA651WRFZ Timer knob 1 AF
3- 4 LHLD-A209WRF0 LED holder 1 AH
3- 5 HPNLCB635WRRZ Control panel 1 AN
3- 6 JBTN-B120WRFZ Select button 1 AC
3- 7 XEPSD30P08XS0 Screw; 3mm x 8mm 7 AA
OVEN PARTS
4- 1 PHOK-A105WRF0 Latch hook 1 AL
4- 2 LANGQA477WRW0 Light mount plate 1 AY
4- 3 PCUSUA502WRP0 Waterproof cushion 1 AD
4- 4 LBNDKA038WRP0 Capacitor holder 1 AF
4- 5 NFANJA043WRE0 Fan blade 1 AK
4- 6 PDUC-A694WRF0 Fan duct 1 AG
4- 7 FOVN-A457WRTZ Oven cavity 1 BD
4- 8 GLEGPA073WRF0 Leg 1 AD
4- 9 LANGTA318WRP0 Chassis support 1 AE
4-10 PCUSGA534WRP0 Cushion 1 AF
4-11 PCOVPA276WRE0 Waveguide cover 1 AM
4-12 PCUSUA500WRP0 Cushion 1 AC
4-13 PPACGA097WRE0 O-ring 1 AG
4-14 PCUSUA443WRP0 Cushion 1 AE
4-15 PCUSGA353WRP0 Cushion 1 AH
DOOR PARTS
5- 1 FDORFA321WRT0 Door panel 1 AT
5- 2 GWAKPA628WRF0 Door frame 1 AY
5- 3 HPNL-A738WRRZ Door screen 1 AS
5- 4 LSTPPA175WRF0 Latch head 1 AE
5- 5 MSPRTA084WRE0 Latch spring 1 AB
5- 6 PSHEPA622WRE0 Sealer film 1 AG
5- 7 GCOVHA390WRF0 Choke cover 1 AK
5- 8 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
MISCLANEOUS
6- 1 FROLPA090WRK0 Turntable support 1 AQ
6- 2 NTNT-A094WRE0 Turntable 1 AN
6- 3 TINSEA850WRRZ Instruction book 1 AG
6- 4 FW-VZB757WRE0 Switch harness 1 AG
6- 5 FW-VZB790WREZ Main wire harness 1 AS
6- 6 TCAUHA214WRR0 K caution label 1 AC
6- 7 TSPCNC913WRRZ Rating label 1 AC
SCREWS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 7 AC
7- 2 LX-EZA042WRE0 Special screw 2 AB
7- 3 LX-WZA028WRE0 Special washer 1 AB
7- 4 XOTSE40P08000 Screw : 4mm x 8mm 4 AA
7- 5 XHTSD40P08RV0 Screw : 4mm x 8mm 5 AA
7- 6 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7- 7 XOTSD40P12RV0 Screw : 4mm x 12mm 9 AA
7- 8 XOTSD40P12000 Screw : 4mm x 12mm 5 AA
7- 9 LX-CZ0052WRE0 Special screw 2 AA
To Next Page
