R-25JT-F
22
VOLTAGE REGULATION FOR "ERROR" INDICATION
Voltage Input to Input to
regulation 208V 230V
*Normal +6% excel. 208.0--220.48 230.0--243.8
*Normal -9% excel. 189.28--208.0 209.3--230.0
*Error.or +6% to 220.48 243.8
indication +13% excel. 235.04 259.9
range -9% to 189.28 209.3
-13% excel. 180.96 200.1
Not over +13% over 235.04 over 259.9
cookable under -13% under 180.96 under 200.1
* Cookable Range
2. Key Unit
The key unit is composed of a matrix circuit in which when
a key it touched, one of signals P30--P34 generated by the
LSI, is passed through the key and returned to the LSI as
one of signals P24--P27.
This model has 20 Memory pads.
When the oven is shipped, Memory pad 1 to 10 are set as
follows: fig.1.
Memory No. Cook Time Output Power
1 10 sec. 100%
2 20 sec. 100%
3 30 sec. 100%
4 45 sec. 100%
51 min. 100%
61 min. 15 sec. 100%
71 min. 30 sec. 100%
82 min. 100%
92 min. 30 sec. 100%
03 min. 100%
(fig. 1)
This model has a double quantity pad. When the oven is
shipped, Magnification "1.8" is preset in the double quan-
tity pad.
This model has an express defrost pad. When the oven is
shipped, express defrost is set as follows: fig.2.
1 STAGE 2 STAGE 3 STAGE
FORMULA P = 0.2T + 20 P = 0.13T + 30 P = 0.67T - 50
POWER 40 % 30 % 20 %
T : Total cooling time
(fig. 2)
When 1/2 total cooking time is passed, the signal will
sound and "CHECK" indicator will flash.
To Next Page
