Sharp R-390AW User Manual

11
R-390Aw
R-390AK
1- 5 Power supply cord FACCDA048WRE0 1 FACCDA075WRE0 1 A Sep./'97 AN
3- 2- 1 Thermistor TH1 Not listed RH-HZA012DRE0 1 C Nov./'97 AL
3- 2- 2 Transistor (KRA101S) Not listed RH-TZA120DRE0 6 C Nov./'97 AE
Q12,Q20,Q40,Q42,Q140,Q160
3- 2- 3 Transistor (KRC101S) Not listed RH-TZA119DRE0 1 C Nov./'97 AE
Q41
3- 2- 4 Transistor (KRA105S) Not listed RH-TZA127DRE0 1 C Nov./'97 AE
Q22
3- 2- 5 Diode (1SS181) Not listed RH-DZA074DRE0 2 C Nov./'97 AE
D20,D50
3- 2- 6 Zener diode (HZM5.6NB2) Not listed RH-DZA076DRE0 1 C Nov./'97 AE
ZD10
3- 2- 7 Lamp LMP1,LMP2 Not listed RLMPHA046DRE0 2 C Nov./'97 AM
3- 2- 8 Transistor (2SA1036K) Not listed RH-TZA130DRE0 1 C Nov./'97 AH
Q141
3- 2- 9 Tact switch Not listed QSW-PA027DRE0 6 C Nov./'97 AG
SW16-SW21
3- 3 Switch unit DPWBFB688WRK0 1 DPWBFB688WRU0 1 Misprint AP
4- 2 Switch holder PHOK-A098WRF0 1 PHOK-A104WRF0 1 A Jul./'97 AF
4- 17 Door stopper LSTPPA162WRF0 1 Deleted 0 D Sep./'97
5 Door assembly CDORFA772WRK0 1 Deleted 0 D Sep./'97
5- 1 Door panel FDORFA303WRT0 1 FDORFA318WRT0 1 D Sep./'97 BE
5- 5 Choke cover GCOVHA370WRF0 1 GCOVHA385WRF0 1 D Sep./'97 AG
6- 8 Instruction book TCADCA639WRR0 1 TCADCA655WRR0 1 C Nov./'97 AY
7- 5 Screw: 4mm X 12mm XOTSD40P12RV0 9 XOTSD40P12RV0 8 A Jun./'97 AA
7- 8 Screw: 4mm X 14mm Not listed XOTSD40P14000 1 C Jun./'97 AA
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authrized SHARP parts Distributor for your area.
Defective parts required return should be returned as indicated in the Service Policy.
INFORMATION OF PARTS CHANGE FOR MODEL R-390AK
The following parts have been changed for the Base model R-390AK.
Interchangeability
A. OLD NEW B. OLD NEW C. OLD NEW D. OLD NEW
REF.NO. DESCRIPTION
REPLACEMENT PART NO.
OLD No.
Q'ty NEW No.
Q'ty
Interchangeability
EFFECTIVE
FROM CODE
INFORMATION OF PARTS CHANGE FOR BOTH MODELS R-390AK AND R-390AW
The following parts will be changed for the both models R-390AK and R-390AW.
Q3 Transistor VSKRC243M//-3 1 VSDTD143ES/-3 1 A Dec./'97 AC
3- 2- 6 Zener diode ZD10 RH-DZA076DRE0 1 RH-DZA077DRE0 1 A Nov./'97
7- 2 Screw: 3mm X 6mm XFPSD30P06000 3 XHPSD30P06000 3 A Dec./'97 AA
