17/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 3 Mounting and installation 23. November 2007
Terminal markings RVS61.843
Use Terminal Connector type
L Mains connection, live AC 230 V
Mains connection, protective earth
N Mains connection, neutral conductor
L
N
AGP4S.03E/109
E9
Low-pressure
E10
High-pressure
K
AGP4S.02J/109
EX1
Multifunctional input EX1
EX2
Multifunctional input EX2
EX3
Multifunctional input EX3
EX4
Multifunctional input EX4
EX5
Multifunctional input EX5
EX6
Multifunctional input EX6
EX7
Multifunctional input EX7
B
AGP8S.07A/109
E11
Overload protection compressor 1
K1
Compressor stage 1
Q
AGP8S.02E/109
N Neutral conductor
Protective earth
Q3 DHW charging pump / diverting valve
R
AGP8S.03A/109
N Neutral conductor
Protective earth
Q2 1st heating circuit pump
S
AGP8S.03B/109
Y1
1st heating circuit mixing valve
opening
N Neutral conductor
Protective earth
Y2
1st heating circuit mixing valve
closing
T
AGP8S.04B/109
N Neutral conductor
Protective earth
Q8
K19
Source pump
Fan
U
AGP8S.03C/109
N Neutral conductor
Protective earth
Q9 Condenser pump
V
AGP8S.03D/109
QX1 1. Multifunctional output
N Neutral conductor
Protective earth
QX2 2. Multifunctional output
W
AGP8S.04E/109
N Neutral conductor
Protective earth
QX3 3. Multifunctional output
X
AGP8S.03E/109
N Neutral conductor
Protective earth
QX4 4. Multifunctional output
Y
AGP8S.03G/109
QX5 5. Multifunctional output
N Neutral conductor
Protective earth
QX6 6. Multifunctional output
Z
AGP8S.04C/109
Mains voltage
