Testing and TroubleshootingPXL Conventional Fire Alarm Control Panel
55
TROUBLESHOOTING
A System trouble condition may result from any of the following
conditions.
PCM-1:
1. The power/data cable from JP2 of the PPS-10M (power supply)
to JP7 of the PCM-1 is not connected or loose.
2. EOL device(s) not connected.
PPS-10M:
1. Power/data cable from JP2 of the PPS-10M (power supply) to
JP7 of the PCM-1 not connected or loose.
2. EOL device(s) not connected.
PRM-4:
1. Power/data cable from JP2 of the PPS-10M (power supply) to
JP7 of the PCM-1 not connected or loose.
2. Power/data cable not connected or loose.
PNC-2Z:
1. Power/data cable from JP2 of the PPS-10M (power supply) to
JP7 of the PCM-1 not connected or loose.
2. Power/data cable not connected or loose.
3. EOL device(s) not connected.
PZE-4B:
1. Power/data cable not connected or loose.
2. EOL device(s) not connected or loose.
LED-3/-4:
1. Power/data cable not connected or loose.
2. Polling LED not pulsing.
RSA-DRIV:
1. Power/data cable not connected or loose.
TABLE 14
PXL FUSE REPLACEMENT
FUSE DESCRIPTION VALUE
F1
F2
F3
F4
XFORM SEC
BATTERY
AUX POWER
+24 VDC
20.0A, 250V, Normal Blow
20.0A, 250V, Normal Blow
1.50A, 250V, Normal Blow
1.00A, 250V, Normal Blow
