C.4 Representation of output ranges
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
187
Table C- 20 Voltage output range 1 V to 5 V
Values
Voltage output range
Range
dec.
hex.
1 to 5 V
>117.589% >32511 >7EFF 5.70 V Maximum output value
117.589%
32511
7EFF
5.70 V
Overrange
27649 6C01
100%
27648
6C00
5 V
Nominal range
75%
20736
5100
4 V
0.003617%
1
1
1 V +144.7 µV
0%
0
0
1 V
-1
FFFF
1 V -144.7 µV
Underrange
-25%
-6912
E500
0 V
<-25%
<-6912
<E500
0 V
Minimum output value
C.4.2
Representation of analog values in the current output ranges
The tables below list the decimal and hexadecimal values (codes) of the possible current
output ranges.
Table C- 21 Current output range ±20 mA
Values
Current output range
Range
dec.
hex.
±20 mA
>117.589%
>32511
>7EFF
23.52 mA
Maximum output value
117.589%
32511
7EFF
23.52 mA
Overrange
27649
6C01
100%
27648
6C00
20 mA
Nominal range
75%
20736
5100
15 mA
0.003617%
1
1
723.4 mA
0%
0
0
0 mA
-1
FFFF
-723.4 mA
-75% -20736 AF00 -15 mA
-100%
-27648
9400
-20 mA
-27649
93FF
Underrange
-117.593%
-32512
8100
-23.52 mA
<-117.593%
<-32512
<8100
-23.52 mA
Minimum output value
