Switching properties
IEEE 802.1Q tags (VLAN ID, priority)
transparent forwarding
Yes
Maximum frame size 1536 bytes
Forwarding of PRP frames (Parallel Redundancy Protocol) Yes
Note
The number of SCALANCE XB-100 modules connected in a line influences the frame delay.
When a frame passes through the IE switch, this is delayed by the store-and-forward function
of the SCALANCE XB-100 by 10-130 microseconds (at 100 Mbps).
Mechanical stability (in operation)
Device IEC 60068-2-27 shock IEC 60068-2-6 vibration
15 g, 11 ms duration
6 shocks per axis
10 - 58 Hz: 0.075 mm
85 - 150 Hz: 1 g
1 octave/min, 20 sweeps
SCALANCE XB108-2(SC) ● ●
SCALANCE XB108-2(ST) ● ●
SCALANCE XB112 ● ●
SCALANCE XB116 ● ●
SCALANCE XB124 ● ●
Technical specifications
7.7 Switching properties
SCALANCE XB-100
40 Operating Instructions, 02/2019, C79000-G8976-C473-03
