Tool management
12
12.1 Machine data for tool management
12.1.1 Settings with/without magazine management
Setting without magazine management
Make the following settings if you are commissioning the tool management without NC
magazine management:
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK Memory for the tool management is re‐
served step-by-step (SRAM).
= 02H
Bit 1 Provide monitoring data.
MD20310 $MC_TOOL_MANAGEMENT_MASK Activating the tool management functions.
= 02H
Bit 1 Monitoring functions of tool management active.
MD17530 $MN_TOOL_DATA_CHANGE_COUNTER Marking the changed tool data for HMI.
= 1FH
Bit 0 Tool status change.
Bit 1 Tool remaining unit quantity change.
Bit 2 Tool data change service.
Bit 3 Magazine data in the change service.
Bit 4 ISO data in the change service.
MD28450 $MC_MM_TOOL_DATA_CHG_BUFF_SIZE Buffer for changing tool data (DRAM).
= 400 Number of entries in the buffer for the OPI change service for tool data. Dynamic memory
is used. This buffer is only created if either bit 2 or bit 3 is set in MD17530 $MN_TOOL_DA‐
TA_CHANGE_COUNTER.
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 163
