Identifier Parameter or property System variable
*)
SpindleDirection For rotating tools, direction of rotation of
the tool spindle. For turning tools, direction
of rotation of the main spindle
$TC_DP25 bit8
and bit9
Coolant1 Coolant 1 $TC_DP25 Bit10
Coolant2 Coolant 2 $TC_DP25 Bit11
MFunction1 M function 1 $TC_DP25 Bit0
MFunction2 M function 2 $TC_DP25 Bit1
MFunction3 M function 3 $TC_DP25 Bit2
MFunction4 M function 4 $TC_DP25 Bit3
IsoHNoDPH ISO H number $TC_DPH
OrientNo Cutting edge orientation $TC_DPV
OrientV1 Cutting edge orientation vector 1 $TC_DPV3
OrientV2 Cutting edge orientation vector 2 $TC_DPV4
OrientV3 Cutting edge orientation vector 3 $TC_DPV5
OrientVGeoAx1 Cutting edge orientation vector of geome‐
try axis 1, cutting edge orientation param‐
eter 3, e.g. vector X
$TC_DPV3
OrientVGeoAx3 Cutting edge orientation vector of geome‐
try axis 3, cutting edge orientation param‐
eter 4, e.g. vector Z
$TC_DPV4
OrientVGeoAx2 Cutting edge orientation vector of geome‐
try axis 2, cutting edge orientation param‐
eter 5, e.g. vector Y
$TC_DPV5
TeethCount Number of teeth, cutting edge parameter
34
$TC_DPNT
BasicRotationAngle Clamping angle of tool, cutting edge pa‐
rameter 35
$TC_DPROT
UniqueDNo Unique D number $TC_DPCE
EdgeUser_1, ..., EdgeUser_10, OEM cutting edge parameters 1 to 10 $TC_DPC1, ...
$TC_DPC10
EdgeAppl_1, ..., EdgeAppl_10x Siemens application cutting edge parame‐
ters 1 to 10
$TC_DPCS1, ...
$TC_DPCS10
*)
Parameter corresponds to the system variable or the system variable is the basis for this parameter.
12.2.2.3 Monitoring parameter identifiers
For the monitoring parameters, the following identifiers are used in the configuration file:
Identifier Parameter or property System variable
*)
SupWarning Warning limits, taking the current monitoring type
into consideration
-
SupRemaining Actual value, taking the current monitoring type into
consideration
-
SupDesired Setpoint, taking the current monitoring type into
consideration
-
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
186 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
