21.10.3.3 Measuring tools at the turning machines
Measuring feedrate for tool measurement in turning operation
SD55628 $SCS_MEA_TP_FEED_MEASURE Calibrate measuring feedrate for tool
probe and measure tool with station‐
ary spindle.
= 300 Default value
Note
Measuring feedrate for tool measuring
All measuring cycles use the value saved in SD54636 or SD54651 as the measuring feedrate
after the tool probe has been calibrated. A different measuring feedrate can be assigned for
each calibration field [n].
When calibrating the probe, either the measuring feedrate from SD55628 is used, or the
measuring feedrate can be overwritten in the input screen when calibrating. To do this,
SD54762 $SNS_MEA_FUNCTION_MASK_TOOL bit 4 must be set to 1.
General cycle machine/setting data for measuring path/feedrate
SD42950 $SC_TOOL_LENGTH_TYP Assignment of the tool length offset
independent of tool type.
= 0 Measuring turning tools, type 5xx (default value)
= 2 Measuring turning tools, type 5xx, drilling and milling tools, type 1xx, 2xx
MD51786 $MNS_J_MEA_T_PROBE_MEASURE_DIST Measuring path to calibrate the
probe or for measurements with sta‐
tionary spindle.
= 10 Default value
SD55628 $SCS_MEA_TP_FEED_MEASURE Feedrate for the calibration of a tool
probe with stationary spindle.
= 300 Default value
Calibrating tool probes
Use the following general cycle machine data to set the access level as of which the "Calibrate
probe" softkey is displayed. This requires that the automatic tool measurement is enabled
using the setting data SD54782 (bit 2 = 1).
MD51070 $MNS_ACCESS_CAL_TOOL_PROBE Calibrate tool probe access level.
= 7 Access rights: Access level 7 (keyswitch 0)
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 633
