Simplicity ZT Series User Manual

11
TP 400-2209-00-AT-SMA
44” Turbo, Blower Group - 1693106
1 108202 2 BEARING
2 960403 1 KEY, Woodruff, Modified
3 1716853 1 SPRING, Tension
4 1665982 4 BEARING, Retainer
5 1668500 1 BRACKET, Anchor, Spring
6 1714255 1 SPACER, Idler Arm
7 1931942 1 PUSHNUT, 3/8
8 1678435 1 BELT STOP
9 1700259 1 DECAL, Danger, Blower
10 1918431 1 WASHER, Plain
11 1705267 1 PLATE, Cover
12 1705492 1 FAN HOUSING (Incl. Ref. No. 9)
13 1717101 1 LEVER ASSY, Turbo (Incl. Ref. Nos. 6 &10)
14 1706465 1 PLATE ASSY.
15 1706631 1 FAN ASSY., 5 Blade
16 1706634 1 PULLEY, Driven
17 1708030 2 IDLER PULLEY ASSY.
18 1717108 1 BRACKET ASSY., Turbo
19 1917356 1 WASHER, Spring Lock, 5/16
20 1917372 1 NUT, Hex, 5/16
21 1921969 1 CAPSCREW, 3/8-16 X 1-1/2
22 1960472 2 SCREW, Truss Hd., 1/4-18 x 5/8
23 1921959 3 CAPSCREW, Hex, 1/4-20 x 5/8
24 1924009 3 CAPSCREW, Hex Hd., 1/4-20 x 3/4
25 1960339 2 NUT, 3/8-16
26 1924874 1 WASHER, Flat
27 1924940 5 WASHER, Plain
28 1925003 1 CAPSCREW, Hex, Taptite, 1/4-20 x 1/2
29 1927557 6 NUT, Flange, Whizlock, 5/16-18
30 1928691 1 SETSCREW, Hex, Socket Hd., 5/16-18 x 5/16
31 1930641 10 NUT, Hex, Flange Lock, 1/4-20
32 1931333 7 CARRIAGE BOLT, 5/16-18 x 3/4
33 1931355 1 CARRIAGE BOLT, 3/8-16 x 2-1/4
34 1708352 1 BELT STOP
35 1933988 6 PUSH NUT, 3/8
36 1924356 1 WASHER
37 1960252 1 CARRIAGE BOLT, 1/4-20 x 5/8
38 1960256 2 SCREW, Washer. Hd.., 1/4-18 x 5/8
39 1922755 3 WASHER
40 1931277 2 NUT, Whizlock, 5/16-18
41 1679164 1 CUP WASHER
42 1960565 1 CARRIAGE BOLT, 5/16-18 x 2-1/2
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693106, 44” Turbo
