Simplicity ZT Series User Manual

13
TP 400-2209-00-AT-SMA
44” Turbo, Mounting Group - 1693106
1 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4” Lg.
2 1717146 1 V-BELT
3 1705070 1 PIVOT ASSEMBLY
4 1931277 5 NUT, Hex Flange, Whiz0lock, 5/16-18
5 1960404 4 CAPSCREW, Truss Head, #10-24 x 3/4” Lg.
6 1933896 6 NUT, Nylock, #10-24
7 1718295 1 ROD, Deflector
8 1921333 2 CAPSCREW, Hex Hd., 5/16-18 x 1” Lg.
9 1919326 2 WASHER, Flat, 11/32
10 1717107 1 SUPPORT STRAP, Deflector
11 960210 1 WASHER, Nylon, 0.388” Dia.
12 1717105 1 COVER, Turbo Belt
13 1919438 2 NUT, Hex, Nylock, 5/16-18
14 1717291 1 DECAL, Warning
15 1921333 1 CAPSCREW, Hex Hd., 5/16-18 x 1” Lg.
16 1717104 1 SUPPORT, Belt Cover
17 1717106 1 STUD, 5/16-18 x 5-3/4” Lg.
18 1715018 1 LATCH, Spring Wire
19 1917372 3 NUT, Hex, 5/16-18
20 1917356 3 LOCKWASHER, 5/16
21 1674315 1 STOP, Belt
22 1924940 1 WASHER, Flat, 3/8
23 1713523 1 NUT, Sleeve
24 1603592 1 WASHER, Belleville
25 1717123 1 PULLEY
26 1713624 1 HUB, Double, 1.160” Long
27 1717109 1 BRACKET, Height Adjustment
28 1679164 1 CUP WASHER
29 1960565 1 CAPSCREW, Rnd Hd., 5/16-18 x 2.5 Lg.
30 1960223 1 CARRIAGE BOLT, 5/16-18 x 1-1/4” Lg.
31 1704880 1 BRACKET ASSEMBLY
32 1666294 1 SPACER
33 1705308 1 BRACKET, “L”
34 1927557 1 NUT, Hex Flange, Whiz-Lock, 5/16-18
35 1922755 1 WASHER, Flat, 13/32
36 1718215 1 LEVER ASSEMBLY, ZT Counterbalance
37 1718214 1 SPRING, Compression
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693106, 44” Turbo
