17
TP 400-2209-00-AT-SMA
Wide Body Cart, Cart Group - 1693108
1 1708211 1 COVER
2 1700763 1 ROD, Straight
3 176012 2 CLIP
4 1700866 1 SLEEVE, Plastic, Connecting
5 1708099 1 CLAMP, Sleeve
6 1700758 1 TUBE, Support
7 1700768 2 HANDLE, Lift
8 1916964 4 LOCKWASHER, 1/4
9 1916622 4 NUT, Hex, 1/4-20
10 1923362 4 NUT, Lock, 5/16-18
11 1919326 6 WASHER, Flat, 5/16
12 1708212 1 HANDLE, Latch
13 177649 2 WASHER, Spring, 5/16
14 1917372 1 NUT, Hex, Full, 5/16-18
15 1920161 1 NUT, Jam, 5/16-18
16 1700267 2 SPACER, Plastic, 5/16
17 1921677 4 CAPSCREW, Hex Hd., 5/16-18 x 1-1/2
18 1919326 4 WASHER, 11/32 x 3/4
19 1921977 1 CAPSCREW, Hex Hd., 5/16-18 x 1-1/4
20 1700761 1 ROD, Support
21 1921210 8 BOLT, Hex, 3/8-16 x 1
22 102004 2 PIN,1/2x 1-1/4
23 1708213 1 FRAME
24 1924940 8 WASHER, Flat, 3/8 S.A.E.
25 1930651 8 NUT, Hex Lock, 3/87-16
26 1676892 2 WHEEL, Swivel, 410/350-4
27 1922134 2 NUT, Hex Lock, 1/2-13
28 1921176 4 CAPSCREW, Hex Hd., 1/2-13 x 1-1/4
29 1700767 1 “U” BRACKET
30 1917372 3 NUT, Hex, 5/16-18
31 1917356 3 LOCKWASHER, 5/16
32 1918249 3 BOLT, Slotted, Truss Hd.
33 1921958 4 CAPSCREW, Hex Hd., 1/4-20 x 1/2
34 1708210 1 BOX
35 1700266 1 STRAP, Rubber, 6”
36 1700762 1 ROD, Support
37 1920397 1 NUT, Nylon insert, 1/4-20
38 176012 2 SAFETY CLIP
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Not Pictured
The above parts group applies to the following Mfg. Nos.:
1693108, Wide Body Dump Cart
