23
TP 400-2209-00-AT-SMA
Clean Sweep & Turbo Clean Sweep Twin Catcher, Cover & Bag Group - 1693150, 1693151
1 960367 2 PIN, Round Head
2 1667248 6 CLIP, Canoe
3 1672023 2 CLAMP
4 1675043 4 RIVET, Pop
5 1675707 2 CLIP, Tube
6 1703700 1 SCREEN
7 1703764 2 BAG, Grass
8 1703807 2 HANGER
9 1703822 1 CROSS ASSY.
10 1703853 1 HANDLE, Latch
11 1703855 2 HOOP, Bag
12 1704056 1 COVER ASSY. (Incl. Ref. Nos. 4, 6, 13, 20, 21, 24, 32 & 39)
13 1704057 1 SEAL, Clip
14 1704075 1 SUPPORT, Tube
15 1704135 1 SEAL, Cover
16 1704180 2 WINDOW
17 1704405 1 DECAL, Safety
18 1704507 1 STRAP, Tube Support
19 1704508 3 BRACKET SEAL
20 1705876 1 CABLE, Double Loop
21 1910531 4 WASHER
22 1917356 4 LOCKWASHER, 5/16
23 1917372 4 NUT, Hex, 5/16-18
24 1921319 1 WASHER, Plain, 1/4
25 1921966 4 CAPSCREW, Hex Hd., 3/8-16 x 7/8
26 1927428 2 SCREW, Taptite, 1/4-20 x 3/8
27 1928352 4 NUT, Hex, Whizlock, 3/8-16
28 1928919 2 NUT, Hex, #10-32
29 1930531 2 SCREW, Truss. Hd., #10-32 x 1/2
30 1930642 5 LOCKNUT, Flange, 1/4-20 End Lock
31 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4
32 1933886 1 NUT, Speed
33 1960077 2 NUT, Hex, Lock, #8-32
34 1960096 2 WASHER
35 1960221 2 CLIP, Hairpin
36 1960252 5 CARRIAGE BOLT, 1/4-20 x 5/8
37 1960381 7 RIVET, Pop
38 1960399 1 SCREW, Round Hd., #8-32 x 7/8
39 1960400 1 SCREW, Self Tapping, #10-12 x 5/8
40 1704615 1 SUPPORT ASSEMBLY, Tube (Incl. Ref. Nos. 14,15,18,19,33,34,37,38)
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693150, Clean Sweep Twin Bag Grass Catcher 1693151, Turbo Clean Sweep Twin Bag Grass Catcher
