Simplicity ZT Series User Manual

35
TP 400-2209-00-AT-SMA
50” Turbo, Mounting Group - 1693228
1 1713540 1 ROLLER
2 1717291 1 DECAL, Warning
3 1707956 1 V-BELT
4 1718214 1 SPRING, Counterbalance
5 1718215 1 LEVER ASSY, Counterbalance
6 1923325 2 CAPSCREW, Hex Hd, 5/16-18 x 7/8
7 1705066 1 PIVOT ASSEMBLY
8 1931277 4 NUT, Hex Whizlock, 5/16-18
9 1960404 4 SCREW, Truss Hd, #10-24 x 3/4
10 1933896 4 NUT, Hex, Nylon Lock, #10-24
11 1718295 1 ROD, Deflector
12 1921333 2 CAPSCREW, Hex Hd, 5/16-18 x 1
13 1919326 3 WASHER, 5/16
14 1718309 1 COVER, Belt
15 1718304 1 SUPPORT, Belt Cover
16 1919438 1 NUT, Hex 5/16-18
17 1921969 1 CAPSCREW, Hex Hd 3/8-16 x 1-1/2
18 1924940 3 WASHER, Flat, 3/8
19 1714817 1 PULLEY ASSEMBLY, Idler
20 1705277 1 LATCH, Belt Cover
21 1704768 1 BRACKET, Idler
22 1916965 1 LOCKWASHER, 3/8
23 1916950 1 NUT, Hex, 3/8-16
24 1705308 1 BRACKET
25 1917356 2 LOCKWASHER, 5/16
26 172845 1 BELT STOP
27 1931335 2 CARRIAGE BOLT, 5/16-18 x 1
28 1713523 1 NUT, Sleeve
29 1603592 1 WASHER, Belleville
30 1709941 1 PULLEY
31 1713634 1 HUB, Double Pulley, 1.16” Long
32 1925003 1 CAPSCREW, Hex Hd, 1/4-20 x 1/2
33 1921319 1 WASHER, 1/4
34 1678435 1 BELT STOP, (Height Indicator)
35 1705064 1 LATCH, Spring
36 1919381 1 WASHER, 5/16
37 1960318 1 CAPSCREW, Hex Hd, 5/16-18
38 1923362 1 NUT, Hex Lock, 5/16-18
39 1679163 1 NUT,Wing, Special, 5/16
40 1917372 3 NUT, Hex, 5/16-18
41 1704982 1 BRACKET, Anchor
42 1704098 1 UPSTOP, Wire
43 1960373 2 CAPSCREW, Hex Washer Hd, Taptite, 5/16
44 1960223 1 CARRIAGE BOLT, 5/16-18
45 1704880 1 BRACKET ASSEMBLY, Cutoff
46 1666294 1 SPACER
47 1960520 1 PUSHNUT
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693228, 50” Turbo

Simplicity ZT Series Specifications

General

Brand	Simplicity
Model	ZT Series
Category	Lawn Mower Accessories
Language	English
