Arm Rest Accessory - 1693427
37
TP 400-2209-00-AT-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
Arm Rest Accessory 1693427 used with seats P/N’s 1715912 & 1718851 ONLY.
‡ Not a Servicable Part.
* Contained in Arm Rest Replacement Kit: LH Arm Rest Repair Kit 1686729
RH Arm Rest Repair Kit 1686728
The above parts group applies to the following Mfg. Nos.:
1 ‡ 1 INSERT TOOL
2 1718852 4 INSERT-NUT, Open End
3 1916965 4 LOCKWASHER, 3/8
4 1921965 4 BOLT, 3/8-16 x 3/4
5 1719363 2 SPRING, Compression
6 ‡ 1 BRACKET, Arm Rest Mounting
7 * 2 ARM REST STOP
8 * 2 SCREW, Tapping, #10 x 5/8
9 * 1 PLATE, Cover, LH
10 * 1 PLATE, Cover, RH
11 * 1 ARM REST, LH
12 * 1 ARM REST, RH
13 * 2 WAVE WASHER
1693427, Arm Rest Accessory
