Design precautions
！ Warning
(1) Actuator drive
When an actuator, such as a cylinder, is driven, take appropriate measures (cover installation or
approach prohibition) to prevent potential danger caused by actuator operation.
(2) Maintenance space
When installing the products, allow access for maintenance.
(3) Ventilation
Provide ventilation when using a valve in a confined area, such as in a closed control panel. for example,
install a ventilation opening, etc., in order to prevent pressure from increasing inside of the confined
area and to release the heat generated by valve.
Selection
！ Warning
(1) Confirm the specifications.
The product is designed for use only in compressed air systems. Do not use fluids other than
compressed air. Do not operate at pressures or temperatures, etc., beyond the range of specifications,
as this can cause damage or malfunction.
(2) Use in low temperature environments
When using the valve in a low temperature condition, take appropriate measures to avoid drainage
freezing, moisture, etc.
Mounting
！ Warning
(1) If air leakage increases or the equipment does not operate properly, stop operation.
Unexpected motion can cause injury.
(2) Check the mounting conditions
Make sure that screws and fittings are properly tightened and the piping is not bent or flattened.
Connect the compressed air supply to the product and perform appropriate functional and leakage
inspections to verify it is mounted properly.
(3) Do not paint the product.
Models or specifications printed or marked on the product should not be erased, removed or covered.
Do not paint resin parts, as this may have an adverse effect due to the solvent in the paint.
