Sonoff D1 User Manual

→ → → → →
1S 1S 1S 1S 1S
Factory Reset
Turn on and off 3 times on repeatedly or delete the connected light on eWeLink
APP until it enters “breathing mode”, then the device is reset successfully and enters
quick pairing mode (Touch).
Please reset the device to factory defaults if you want to use other Wi-Fi networks,
then reconnect the network.
SONOFF TECHNOLOGIES CO., LTD.
English
9
Dev ice Settin gs
LAN c ontro l
Dev ice Settin gs
Pow er-on S tate
ON
Set b right ness ra nge
Dev ice inf o
Man ufact urer
Mod el
Dev ice ID
Mac a ddres s
FW Na me
Delete device
D1
Sche dule Time r

Sonoff D1 Specifications

General

Model	Sonoff D1
Category	Switch
Input Voltage	100-240V AC 50/60Hz
Output	100-240V AC 50/60Hz
Dimming Range	1%-100%
Operating Temperature	-10°C to 40°C
Operating Humidity	5%-95% RH, non-condensing
Casing Material	PC V0
MCU	ESP8266
Certification	CE, FCC
Wireless Standard	802.11 b/g/n
Control	App, RF Remote, Voice Control
