Sonoff TH Elite User Manual

Shenzhen Sonoff Technologies Co., Ltd.
English
2. Wiring instruction
2-1 Remove protective cover
2-2
L In
N
N
L In
LOut
N
100-240V AC
2-3 Wiring method of dry contact
TH Elite
Press the white button on the top of the wire connecting hole to insert the wire
corresponding, then release.
Dry contact wire conductor size: 0.13-0.5mm², wire stripping length: 9-10mm.
Make sure all wires are connected correctly.
11
9-10mm
