XR-77A80K / 65A80K / 55A80K
5-037-709-11(1)
7
GB
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM:
48 kHz 16 bits, Dolby Audio, DTS)
(Stereo mini jack)
Headphone
1, 2
USB port 1 supports High Speed USB (USB 2.0)
USB port 2 supports Super Speed USB (USB 3.2
Gen 1)
LAN
10BASE-T/100BASE-TX connector (Depending
on the operating environment of the network,
connection speed may differ. The
communication rate and quality are not
guaranteed.)
Power and others
Power requirements
220V – 240V AC, 50Hz
Screen size (measured diagonally) (Approx.)
XR-77A80K: 77 inches / 194.7 cm
XR-65A80K: 65 inches / 163.9 cm
XR-55A80K: 55 inches / 138.8 cm
Power consumption
Indicated on the rear of the TV
Standby power consumption*
6
*
7
0.5 W
Display resolution (horizontal × vertical) (pixels)
3840 × 2160
Output rating
500 mA (for USB 1), 900 mA (for USB 2)
Dimensions (Approx.) (w × h × d) (mm)
with Table-Top Stand
Standard position:
XR-77A80K: 1722 × 1024 × 389
XR-65A80K: 1448 × 862 × 330
XR-55A80K: 1227 × 738 × 330
Narrow position:
XR-77A80K: 1722 × 1024 × 389
XR-65A80K: 1448 × 862 × 330
XR-55A80K: 1227 × 738 × 330
Soundbar position:
XR-77A80K: 1722 × 1066 × 389
XR-65A80K: 1448 × 904 × 330
XR-55A80K: 1227 × 780 × 330
without Table-Top Stand
XR-77A80K: 1722 × 998 × 54
XR-65A80K: 1448 × 836 × 53
XR-55A80K: 1227 × 712 × 53
Stand width (Approx.) (mm)
Standard position:
XR-77A80K: 1409
XR-65A80K / 55A80K: 1184
Narrow position:
XR-77A80K: 619
XR-65A80K / 55A80K: 847
Soundbar position:
XR-77A80K: 1409
XR-65A80K / 55A80K: 1184
Mass (Approx.) (kg)
with Table-Top Stand
XR-77A80K: 37
XR-65A80K: 24.6
XR-55A80K: 19.5
without Table-Top Stand
XR-77A80K: 34.8
XR-65A80K: 23
XR-55A80K: 17.9
Others
Optional accessories
Wall-Mount Bracket: SU-WL850 / SU-WL450
Camera and Microphone Unit: CMU-BC1
Operating temperature: 0 ºC – 40 ºC
Operating humidity: 10 % – 80 % RH
(non-condensing)
*1 When 4096 × 2160p is input and [Wide mode] is set
to [Normal], the resolution is displayed as 3840 ×
2160p. To display 4096 × 2160p, set [Wide mode]
setting to [Full 1] or [Full 2].
*2 Refer to the on screen menu to set [HDMI signal
format].
*3 Refer to the online Help Guide for details.
*4 HDMI IN 3 & 4 only. Use the Ultra High Speed HDMI
Cable to connect.
*5 Connect your audio system to the HDMI IN 3 to route
TV audio to your audio system.
*6 Specified standby power is reached after the TV
finishes necessary internal processes.
*7 Standby power consumption will increase when
your TV is connected to the network.
Note
• Optional accessories availability depends on
countries/region/TV model/stock.
• Design and specifications are subject to change
without notice.
• Subscriptions for services and applications may be
required and additional terms, conditions and/or
charges may apply when using Google Assistant.
