Sony CCP-8000 System Setup Manual

3-37
MVS-8000 System
SYSTEM SETUP
MVS-8000 Matrix assignment
Bit No. Source
1 Primary 1
2 Primary 2
3 Primary 3
4 Primary 4
5 Primary 5
6 Primary 6
7 Primary 7
8 Primary 8
9 Primary 9
10 Primary 10
11 Primary 11
12 Primary 12
13 Primary 13
14 Primary 14
15 Primary 15
16 Primary 16
17 Primary 17
18 Primary 18
19 Primary 19
20 Primary 20
21 Primary 21
22 Primary 22
23 Primary 23
24 Primary 24
25 Primary 25
26 Primary 26
27 Primary 27
28 Primary 28
29 Primary 29
30 Primary 30
31 Primary 31
32 Primary 32
33 Primary 33
34 Primary 34
35 Primary 35
3-7. Tally Setup
3-7-7. Setting Serial Tally
The Serial Tally signal is output from the Serial Tally 1 terminal and the Serial Tally 2 terminal of the MKS-8700.
Ver. 1.20 does not support the Serial Tally setup. The fixed tally output is supported.
In Ver. 1.20, the fixed tallies of R-1, G-1, R-2 and G-2 are output from Serial Tally 1 terminal of the MKS-8700.
Tally signal is output according to the protocol attached as APPENDIX. For details, please refer to the “BVS-3000 Series,
DVS-8000 Series PROTOCOL and COMMAND SPECIFICATIONS (Sony Part No. : 9-967-262-21)”.
Bit assignment is shown in the following table.
Bit No. Source
36 Primary 36
37 Primary 37
38 Primary 38
39 Primary 39
40 Primary 40
41 Primary 41
42 Primary 42
43 Primary 43
44 Primary 44
45 Primary 45
46 Primary 46
47 Primary 47
48 Primary 48
49 Primary 49
50 Primary 50
51 Primary 51
52 Primary 52
53 Primary 53
54 Primary 54
55 Primary 55
56 Primary 56
57 Primary 57
58 Primary 58
59 Primary 59
60 Primary 60
61 Primary 61
62 Primary 62
63 Primary 63
64 Primary 64
65 Primary 65
66 Primary 66
67 Primary 67
68 Primary 68
69 Primary 69
70 Primary 70
