Sony DCR-TRV33 User Manual

— 5 —
DCR-TRV33/TRV33E
1. SELF-DIAGNOSIS FUNCTION
When problems occur while the unit is operating, the self-diagnosis
function starts working, and displays on the viewfinder, or LCD
screen what to do.
Details of the self-diagnosis functions are provided in the Instruction
manual.
2. SELF-DIAGNOSIS DISPLAY
When problems occur while the unit is operating, the counter of the
viewfinder or LCD screen consists of an alphabet and 4-digit number,
which blinks at 3.2Hz. This 5-character display indicates the
“repaired by:”, “block” in which the problem occurred, and “detailed
code” of the problem.
1 1
3 1C
Repaired by:
Refer to page 6.
Self-diagnosis Code Table.
Indicates the appropriate
step to be taken.
E.g.
31 ....Reload the tape.
32 ....Turn on power again.
Block
Detailed Code
Blinks at 3.2Hz
C : Corrected by customer
H : Corrected by dealer
E : Corrected by service
engineer
Viewfinder or LCD screen
C : 3 1 : 1 1
SELF-DIAGNOSIS FUNCTION
COVER
COVER
Note: The “self-diagnosis display” data will be kept even if the lithium battery (BT5201 of CK-129 board) is removed.

Sony DCR-TRV33 Specifications

General

Total megapixels	1 MP
Optical sensor size	1/4.7 \
Filter size	30 mm
Optical zoom	10 x
Focal length range	3.7 - 37 mm
Flash memory	8 MB
Minimum illumination	7 lx
Built-in microphone	Yes

Weight and Dimensions

Depth	90 mm
Width	71 mm
Height	112 mm
Weight	540 g
