Sony DSC-HX90V User Manual

Hint
To store the viewfinder
Grasp both sides of the eyepiece and push it into the viewfinder until it clicks. Then push
down the viewfinder.
Note
Be careful not to push down on the viewfinder when it is being raised.
Be sure that the eyepiece is stored in the viewfinder unit before attempting to push down
the viewfinder. If it is not stored and you try to force the viewfinder down, a malfunction
may result.
Do not carry the camera by the viewfinder.
[6] How to Use
Before Use In-Camera guide
About the [In-Camera Guide]
The [In-Camera Guide] displays descriptions of MENU items, Fn (Function) button, and
settings, and if a function cannot be set, the reason why.
1. Press the MENU or Fn button.
2. Select the desired MENU item using up/down/left/right side on the control wheel.
3. Press the / (In-Camera Guide/Delete) button.
The operation guide for the MENU item you have selected in step 2 is displayed.
If you press the on the center of the control wheel after selecting an item shown
in gray, the reason the item cannot be set is displayed.

Sony DSC-HX90V Specifications

General

Effective Pixels	18.2 MP
Optical Zoom	30x
Lens	ZEISS Vario-Sonnar T*
Focal Length	4.1-123mm
Aperture Range	f/3.5-6.4
Image Stabilization	Optical SteadyShot
ISO Sensitivity	80-12800
Display Type	3.0" TFT LCD
Built-in Flash	Yes
Connectivity	Wi-Fi, NFC, Micro HDMI, Micro USB
Battery Type	NP-BX1
Sensor Type	1/2.3" Exmor R CMOS sensor
Digital Zoom	Up to 120x
Shutter Speed	iAuto (4''-1/2000) / Program Auto (1''-1/2000)
Continuous Shooting Speed	10 fps
Viewfinder	0.2" type electronic viewfinder
Video Resolution	Full HD 1920x1080 at 60p/60i/24p
Battery Life	Approx. 390 shots (CIPA standard)
Weight	Approx. 245 g with battery and memory card
