7-59
DSR-2000A/2000AP
7-21. HC Roller Assembly Replacement
Outline
Replacement
Disconnecting the connector
Removing the head cleaner assembly
Replacing the HC roller assembly
Reattaching the head cleaner assembly
Reconnecting the connector
Note
Prepare a new stop washer when replacing the HC roller assembly.
Stop washer (0.8) : 3-315-414-31 x 1
Bare-handed touch to the HC roller assembly is prohibited. Do put on cloth gloves
before replacing.
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Washer extracting fixture (A) : J-6082-234-A
. Washer mounting fixture Ø1.8 : J-6082-233-A
To Next Page
