Sony DSX-B710D Service Manual

DSX-B700/B700W/B710D
16
Sony CONFIDENTIAL
For Authorized Servicer
SECTION 3
DISASSEMBLY
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
3-7. HOW TO INSTALL THE AUX JACK (J901)
AND THE USB CONNECTOR (CN902)
(Page 22)
SET
3-8. HOW TO INSTALL THE KNOB (VOL) ASSY
(Page 23)
3-2. MINI FUSE (BLADE TYPE),
FRONT PANEL BLOCK
(Page 17)
3-4. CONNECTION CABLE (SMB)
(Page 19)
3-5. MAIN BOARD
(Page 20)
3-6. KNOB (VOL) ASSY, KEY BOARD,
FRONT PANEL ASSY
(Page 21)
3-3. CHASSIS TOP
(Page 18)
Note:
Due to the structure of the unit, you cannot stably
place it on flat surfaces.
Stabilize the unit by placing a stand, etc. under it
that is suitable for your work.
(DSX-B710D)
stand, etc.
SYSSET
2019/10/2421:43:03(GMT+09:00)

Sony DSX-B710D Specifications

General

DIN size	2 DIN
Output power	55 W
RDS features	EON
Product color	Black
Volume control	Rotary
Disc types supported	No
Audio output channels	- channels
Equalizer bands quantity	10
Maximum power per channel	- W
Smartphone remote support	Yes
USB version	2.0
Bluetooth version	3.0
Bluetooth profiles	AAC, SBC
USB ports quantity	1
Supported radio bands	AM, DAB+, FM, LW
Audio formats supported	CUE, FLAC
Display type	LCD
Illumination color	Blue, Green, Red
Sustainability certificates	CE

Weight and Dimensions

Depth	177 mm
Width	178 mm
Height	100 mm
Weight	1000 g
