14
HCD-FC8/FC9
3-6. DVD BOARD, DC FAN
qj
DVD board
3
two screws
(+BVTP 3
×
8)
5
two screws
(+BVTP 3
×
8)
1
two screws
(+BVTP 3
×
8)
2
DC FAN
8
wire (flat type)(CN001)
9
wire (flat type)(CN004)
qa
wire (flat type)(CN003)
7
wire (flat type)(CN002)
qs
wire (flat type)(CN401)
0
connector (CN008
)
4
sheet
qd
sheet
6
power bracket
qf
sheet
qg
sheet
qh
sheet
