Sony HCD-M60D Service Manual

HCD-M40D/M60D/M80D
16
2-7. SERVICE, OPTICAL DEVICE (7G), FLEXIBLE FLAT CABLE
Under the guide
Under the guide
(Fold area)
,QVWDOODWLRQRIIOH[LEOHIODWFDEOHFRUHDQGIOH[LEOHIODWFDEOHFRUH
Note:
This illustration sees the loading assy (MB) from bottom side.
1 flexible flat cable
(24 core)
2 Through the hole
3 Through the hole
4
terminal face
loading assy (MB)
7 flexible flat cable
(24 core)
6 holder, FFC
5 three claws
5 two claws
0 flexible flat cable
(5 core)
9 filament tape
(sub material)
8 filament tape
(sub material)
7 four insulator screws
0 connector
qa insulator
6 belt
3 Insert the thin
wire (clip etc.).
5 tray
qs service, optical
device (7G)
qa insulator
qa insulator
qj
ql flexible flat cable
(24 core)
1 six claws
4
9
8
2 chuck holder assy
(MB)
qg flexible flat cable
(5 core)
– Bottom view –
loading assy
(MB)
qd base, lo
qk holder, FFC
qf filament tape
(sub material)
qh filament tape
(sub material)
filament tape
(sub material)
:LUHVHWWLQJ
