HCD-S20
HCD-S20
3030
• : Uses unleaded solder.
• See page 20 for Circuit Boards Location.
VFD BOARD (COMPONENT SIDE)
VFD BOARD (CONDUCTOR SIDE)
A
B
C
1 2 3 4 5 6
6-14. PRINTED WIRING BOARD - VFD Board -
