Sony HDR-CX530E User Manual

6-29
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
VC-1025
(25/26)
CN4004
(PAGE 6-27)
CM-1004
CN6702
(PAGE 6-2)
12 3 4
A
B
C
D
E
F
A
B
C
D
E
F
08
FP-2189 FLEXIBLE BOARD
CM-VC CONNECTION
(PRINTED WIRING BOARD is omitted.)
LND00139P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
LND00239P
1
REG_GND
2
REG_GND
3
CLK_CMOS_IN_IMG
4
REG_GND
5
REG_GND
6
XFLASH_RST
7
REG_GND
8
IC_6000_SENSXCS
9
IC_6000_SENSSCK
10
REG_GND
11
IC_6000_SENSSO
12
IC_6000_SENSSI
13
SENS_HD
14
SENS_VD
15
REG_GND
16
REG_GND
17
SUBL_DINN7
18
SUBL_DINP7
19
REG_GND
20
REG_GND
21
SUBL_DINN6
22
SUBL_DINP6
23
REG_GND
24
REG_GND
25
SUBL_CLKINN
26
SUBL_CLKINP
27
REG_GND
28
REG_GND
29
SUBL_DINN5
30
SUBL_DINP5
31
REG_GND
32
REG_GND
33
SUBL_DINN4
34
SUBL_DINP4
35
REG_GND
36
REG_GND
37
AVDD18_SUBL
38
D1.2V
39
A3.3V
REG_GND
REG_GND
INCK
REG_GND
REG_GND
XCLR
REG_GND
XCE
SCK
REG_GND
SDI
SDO
XHS
XVS
REG_GND
REG_GND
DOAM
DOAP
REG_GND
REG_GND
DOBM
DOBP
REG_GND
REG_GND
DCKM
DCKP
REG_GND
REG_GND
DOCM
DOCP
REG_GND
REG_GND
DODM
DODP
REG_GND
REG_GND
I/F_1.8V
CAM_1.2V
CMOS_A_3.3V
VC-1025
(25/26)
CN4006
(PAGE 6-27)
MM-102
(1/2)
CN8101
(PAGE 6-30)
12 3 4
A
B
C
D
E
F
A
B
C
D
E
F
08
FP-2060 FLEXIBLE BOARD
EXCEPT CX530E
VC-MM CONNECTION
(PRINTED WIRING BOARD is omitted.)
LND002 18P
1 REG_GND
2 TE1_DAT_7
3 TE1_DAT_2
4 TE1_DAT_6
5 TE1_DAT_1
6 TE1_DAT_5
7 TE1_DAT_0
8 TE1_DAT_4
9 TE1_DAT_3
10 REG_GND
11 TE1_CLK
12 REG_GND
13 TE1_CMD
14 REG_GND
15 TE1_VCC
16 MMC_PWR_ON1
17 MEDIA_3.3V
18 MEDIA_3.3V
LND00118P
1MEDIA_3.3V
2MEDIA_3.3V
3MMC_PWR_ON1
4MMC_VCC
5REG_GND
6MMC_CMD
7REG_GND
8MMC_CLK
9REG_GND
10MMC_DAT_3
11MMC_DAT_4
12MMC_DAT_0
13MMC_DAT_5
14MMC_DAT_1
15MMC_DAT_6
16MMC_DAT_2
17MMC_DAT_7
18REG_GND
