Ref. No. Part No. Description
Ref. No. Part No. Description
Ref. No. Part No. Description
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
2-5E
R3202 1-218-977-11 METAL CHIP 100K 5% 1/16W
(Projector Model)
R3303 (Not supplied) METAL CHIP 240 1% 1/20W
(Projector Model)
R3501 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R4016 1-218-989-11 METAL CHIP 1M 5% 1/16W
R4018 1-218-945-11 METAL CHIP 220 5% 1/16W
R4019 1-218-945-11 METAL CHIP 220 5% 1/16W
R4020 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4021 1-240-695-91 METAL CHIP 1K 5% 1/20W
R4025 1-240-700-91 METAL CHIP 2.7K 5% 1/20W
(Projector Model)
R4025 1-240-707-91 METAL CHIP 10K 5% 1/20W
(Non Projector Model)
R4029 1-240-700-91 METAL CHIP 2.7K 5% 1/20W
R4030 1-240-705-91 METAL CHIP 6.8K 5% 1/20W
(Projector Model)
R4033 1-240-707-91 METAL CHIP 10K 5% 1/20W
R4034 1-240-707-91 METAL CHIP 10K 5% 1/20W
R4901 1-240-711-91 METAL CHIP 22K 5% 1/20W
(Non Projector Model)
R4901 1-694-535-91 SHORT CHIP 0 (Projector Model)
R4904 1-240-714-91 METAL CHIP 47K 5% 1/20W
R4905 1-240-718-91 METAL CHIP 100K 5% 1/20W
(Non Projector Model)
R4907 1-694-535-91 SHORT CHIP 0
R5100 (Not supplied) METAL CHIP 47K 1% 1/20W
* R5150 1-250-546-11 METAL CHIP 130K 1% 1/16W
R5151 1-250-519-11 METAL CHIP 10K 1% 1/16W
R5200 1-218-941-81 METAL CHIP 100 5% 1/16W
R5201 (Not supplied) METAL CHIP 100K 1% 1/20W
* R5202 1-257-273-11 METAL CHIP 33K 1% 1/20W
R5300 1-250-449-11 METAL CHIP 12 1% 1/16W
R5301 1-250-449-11 METAL CHIP 12 1% 1/16W
R5500 1-240-707-91 METAL CHIP 10K 5% 1/20W
R5600 1-240-714-91 METAL CHIP 47K 5% 1/20W
R5630 1-240-711-91 METAL CHIP 22K 5% 1/20W
* R5631 1-257-267-11 METAL CHIP 18K 1% 1/20W
R5650 1-240-679-91 METAL CHIP 47 5% 1/20W
* R5654 1-250-503-11 METAL CHIP 2.2K 1% 1/16W
R5655 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R5656 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R5701 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R5702 1-240-697-91 METAL CHIP 1.5K 5% 1/20W
R5711 1-240-711-91 METAL CHIP 22K 5% 1/20W
R5712 1-240-677-11 METAL CHIP 27 5% 1/20W
R5713 1-240-677-11 METAL CHIP 27 5% 1/20W
R6001 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6002 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6041 1-240-695-91 METAL CHIP 1K 5% 1/20W
* R6060 1-257-249-11 METAL CHIP 3.3K 1% 1/20W
* R6061 1-257-249-11 METAL CHIP 3.3K 1% 1/20W
R6062 (Not supplied) METAL CHIP 12K 1% 1/20W
R6081 1-240-683-91 METAL CHIP 100 5% 1/20W
R6082 1-240-683-91 METAL CHIP 100 5% 1/20W
R6084 1-240-683-91 METAL CHIP 100 5% 1/20W
R6085 1-240-684-91 METAL CHIP 120 5% 1/20W
R6120 (Not supplied) METAL CHIP 240 1% 1/20W
R6121 (Not supplied) METAL CHIP 240 1% 1/20W
R6123 (Not supplied) METAL CHIP 240 1% 1/20W
R6124 (Not supplied) METAL CHIP 10K 1% 1/20W
R6125 (Not supplied) METAL CHIP 10K 1% 1/20W
R6800 1-240-812-11 METAL CHIP 15K 0.5% 1/20W
R6801 1-250-553-11 METAL CHIP 270K 1% 1/16W
R6802 1-250-553-11 METAL CHIP 270K 1% 1/16W
R6803 1-240-707-91 METAL CHIP 10K 5% 1/20W
R6804 1-240-707-91 METAL CHIP 10K 5% 1/20W
R7101 1-240-729-91 METAL CHIP 1M 5% 1/20W
R7711 (Not supplied) METAL CHIP 15K 1% 1/20W
R7712 (Not supplied) METAL CHIP 150K 1% 1/20W
R7713 (Not supplied) METAL CHIP 10K 1% 1/20W
R7714 (Not supplied) METAL CHIP 22K 1% 1/20W
R7715 (Not supplied) METAL CHIP 22K 1% 1/20W
R8500 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R8501 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R8502 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R8503 1-208-667-11 METAL CHIP 220 0.5% 1/16W
R8504 1-208-667-11 METAL CHIP 220 0.5% 1/16W
R8505 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R8506 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R8507 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R8508 1-240-722-91 METAL CHIP 220K 5% 1/20W
R8800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8801 1-250-567-11 METAL CHIP 1M 1% 1/16W
R9000 1-240-712-91 METAL CHIP 27K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
* RB0200 1-234-384-11 RES, NETWORK 1M (1005X4)
RB0500 1-234-381-11 RES, NETWORK 100K (1005X4)
RB1081 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB3100 1-234-380-21 RES, NETWORK 47K (1005X4)
RB3357 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3358 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3359 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3360 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3502 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(Projector Model)
RB3503 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(Non Projector Model)
* RB4000 1-234-384-11 RES, NETWORK 1M (1005X4)
RB4001 1-234-380-21 RES, NETWORK 47K (1005X4)
* RB4002 1-234-723-21 RES, NETWORK 75 (1005X4)
RB4010 1-234-372-11 RES, NETWORK 100 (1005X4)
(Non Projector Model)
RB4011 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(Projector Model)
RB5700 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6080 1-200-051-21 RES, NETWORK 150 (1005X4)
RB6082 1-234-372-11 RES, NETWORK 100 (1005X4)
RB8201 1-234-380-21 RES, NETWORK 47K (1005X4) (Projector Model)
RB9000 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
* SE4010 1-487-118-31 GMR SENSOR (Projector Model)
* SE4011 1-487-118-31 GMR SENSOR (Non Projector Model)
SE7711 (Not supplied) SENSOR, ANGULAR VELOCITY
< VARISTOR >
VD0500 1-802-090-21 VARISTOR, CHIP
VD0501 1-802-090-21 VARISTOR, CHIP
VD0502 1-802-090-21 VARISTOR, CHIP
VD4018 1-802-090-21 VARISTOR, CHIP
< VIBRATOR >
X5700 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
X5701 1-814-304-11 VIBRATOR, CRYSTAL (12MHz)
* X6000 1-813-403-81 QUARTZ CRYSTAL OSCILLATOR (12MHz)
X8200 1-814-515-11 QUARTZ CRYSTAL OSCILLATOR (28.636363MHz)
(Projector Model)
A-1992-200-A WF-1004 BOARD, COMPLETE (EXCEPT CX535)
***********************
(C7402, CP7300, ET2301 and L2303 are not supplied, but they are included in WF-
1004 COMPLETE BOARD.)
< CAPACITOR >
* C2305 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2307 1-117-730-81 CERAMIC CHIP 1.2PF 0.1PF 16V
C7301 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7302 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7303 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7304 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7305 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
* C7401 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7402 (Not supplied) CERAMIC CHIP 100PF 1% 50V
< CONNECTOR >
CN2301 1-821-858-61 CONNECTOR, FPC (LIF (NON-ZIF)) 24P
CN2302 1-794-375-21 PIN, CONNECTOR 2P
< COMPOSITION CIRCUIT BLOCK >
CP7300 (Not supplied) WLAN MODULE
< ON BOARD CONTACT >
ET2301 (Not supplied) ON BOARD CONTACT
< IC >
* IC7401 6-715-114-01 IC CXD9950AK
< COIL >
L2303 (Not supplied) INDUCTOR 3.3nH
< COMPOSITION CIRCUIT BLOCK >
RB7301 1-234-372-11 RES, NETWORK 100 (1005X4)
RB7302 1-234-372-11 RES, NETWORK 100 (1005X4)
VC-1025 WF-1004
