Sony MHC-NX1 Operating Instructions (primary manual) User Manual

5
FM 75Ω
AM
AM
FM 75 Ω
COAXIAL
+
–
R
L
+
Insert only the stripped portion.
Black/
Stripe (’)
Red/
Solid (‘)
1 Connect the flat cord to the SYSTEM
CONTROL connectors until it clicks.
2 Connect the front speakers.
Connect the speaker cords to the FRONT
SPEAKER jacks as below.
Note
Keep the speaker cords away from the
antennas to prevent noise.
continued
To disconnect
AM loop aerial
Extend the FM lead
aerial horizontally.
Jack type B
AM loop aerial
Extend the FM lead
aerial horizontally.
3 Connect the FM/AM antennas.
Set up the AM loop antenna, then
connect it.
Jack type A
Note
Set up the AM loop antenna as far as possible from
the main unit.
