242
Applying Special Effects (Edge Effects)
Chapter 11 DME Operations
Edges cannot be softened when the Crop effect is
disabled.
To specify whether to invert the crop area when
inverting the video image
In the <Invert/Crop Process> group, select either of the
following.
Crop –> Invert: Set an axis of symmetry at the center of
the input video, and invert both the desired area of
video and the crop area horizontally and vertically
around that axis of symmetry. The order of effect
application is Crop > Invert.
Invert –> Crop: Set an axis of symmetry at the center of
the input video, and invert only the desired area of
video horizontally and vertically around that axis of
symmetry. The order of effect application is Invert >
Crop.
Beveled Edge Settings
Applying a beveled edge
1
In the DME menu, select VF1 ‘Edge’ and HF2
‘Beveled Edge.’
The Beveled Edge menu appears.
2
Press [Beveled Edge], turning it on.
3
Set the parameters.
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
4:3 mode
16:9 mode
4
In the <Edge Mode> group, select the type of edge.
Light: effect of light striking the edge
Color: colored edges. When this is selected, set the
following parameters in the <Color Adjust>
group.
• To set the density
• To set the colors for each edge (Top, Left, Right,
Bottom, All)
Knob Parameter Adjustment Setting values
1 Soft Softness of
edges
0.00 to 100.00
Notes
Knob Parameter Adjustment Setting values
1 H Simultaneou
sly adjust
width of left
and right
edges
0.00 to 4.00 (SD)
0.00 to 12.00 (HD)
2 V Simultaneou
sly adjust
width of top
and bottom
edges
0.00 to 3.00 (SD)
0.00 to 9.00 (HD)
3 All Simultane-
ously adjust
width of all
four edges
Value of H shown
Knob Parameter Adjustment Setting values
1 H Simultane-
ously adjust
width of left
and right
edges
0.00 to 4.00 (SD)
0.00 to 16.00 (HD)
2 V Simultane-
ously adjust
width of top
and bottom
edges
0.00 to 2.25 (SD)
0.00 to 9.00 (HD)
3 All Simultane-
ously adjust
width of all
four edges
Value of H shown
Knob Parameter Adjustment Setting values
1Top Adjust
luminance of
top edge
–100.00 to +100.00
2 Left Adjust
luminance of
left edge
–100.00 to +100.00
3 Right Adjust
luminance of
right edge
–100.00 to +100.00
4 Bottom Adjust
luminance of
bottom edge
–100.00 to +100.00
5 All Simultaneou
sly adjust
luminance of
all four
edges
Value of Left shown
Knob Parameter Adjustment Setting values
1 Density Adjust the
color density
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
a)
Knob Parameter Adjustment Setting values
